3-20
R342 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
R343 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R344 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R345 NRSA63J-681X MG RESISTOR 680 Ω 1/16W J
R409 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
R413 NRSA63J-103X MG RESISTOR 10k
Ω 1/16W J
R414 NRSA63J-103X MG RESISTOR 10k
Ω 1/16W J
R415 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R416 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R501 NRSA63J-470X MG RESISTOR 47 Ω 1/16W J
R513 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
R514 NRSA63J-220X MG RESISTOR 22 Ω 1/16W J
R550 NRSA63J-471X MG RESISTOR 470 Ω 1/16W J
R565 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R566 NRVA63D-122X CMF RESISTOR 1.2k Ω 1/16W D
R567 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R568 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R569 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R570 NRSA63J-100X MG RESISTOR 10 Ω 1/16W J
R572 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R573 NRSA63J-162X MG RESISTOR 1.6k
Ω 1/16W J
R574 NRSA63J-162X MG RESISTOR 1.6k
Ω 1/16W J
R575 NRSA63J-151X MG RESISTOR 150 Ω 1/16W J
R576 NRSA63J-151X MG RESISTOR 150 Ω 1/16W J
R578 NRSA63J-151X MG RESISTOR 150 Ω 1/16W J
R583 NRSA63J-101X MG RESISTOR 100 Ω 1/16W J
R584 NRSA63J-332X MG RESISTOR 3.3k Ω 1/16W J
R589 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
L501 NQL044K-100X COIL 10uH K
CN101 QGF0501F2-24X CONNECTOR FFC/FPC (1-24)
CN103 QGF1037F1-15W CONNECTOR FFC/FPC (1-15)
CN104 QGA2001F2-02X CONNECTOR W-B (1-2)
CN105 QGA2001F2-03X CONNECTOR W-B (1-3)
CN201 QGF1037F1-15W CONNECTOR FFC/FPC (1-15)
CN501 QGF1016C2-07W CONNECTOR FFC/FPC (1-7)
CN502 QGF1016C2-23W CONNECTOR FFC/FPC (1-23)
K101 NQR0007-002X FERRITE BEADS
K501 NQR0007-002X FERRITE BEADS
K508 NQR0007-002X FERRITE BEADS
K509 NQR0007-002X FERRITE BEADS
K556 NQR0129-002X FERRITE BEADS
K557 NQR0129-002X FERRITE BEADS
K558 NQR0129-002X FERRITE BEADS
K559 NQR0129-002X FERRITE BEADS
K560 NQR0007-002X FERRITE BEADS
X301 NAX0566-001X C RESONATOR 16.934MHz
X401 NAX0248-001X C OSCILLATOR
X571 NAX0550-001X CRYSTAL 27.000MHz
 Symbol No. Part No. Part Name Description Local
