JVC TH M45 Service Manual

3-13
DSP board
Block No. [0][3][0][0]
 Symbol No. Part No. Part Name Description Local
IC151 BU4066BCF-X IC Source selector
IC153 M62446AFP-X IC
6 channel
electronic volume
IC158 NJM4565M-WE IC Dual ope amp
IC159 NJM4565M-WE IC Dual ope amp
IC160 NJM4565M-WE IC Dual ope amp
IC401 AK4527BVQP IC A/D D/A converter
IC402 MM1613DN-X IC Regulator
IC403 TC9446F-025 IC
Audio digital
processor
IC404 LP61L1024S-12-X IC SRAM
IC406 UPD784215AGC167 IC(MICRO C ROM)
Digital signal
controller
IC407 MM1563DF-X IC Regulator
IC408 74VHC00SJ-X IC
Quad 2-input
NAND gate
IC409 GP1FA352RZ OPT RECEIVER
Optical fiber data
kink receive unit
IC510 BA15218F-XE IC
Dual operational
amplifier
IC511 BA15218F-XE IC
Dual operational
amplifier
IC531 BA15218F-XE IC
Dual operational
amplifier
IC561 BA15218F-XE IC
Dual operational
amplifier
IC581 BA15218F-XE IC
Dual operational
amplifier
IC591 BA15218F-XE IC
Dual operational
amplifier
Q401 KRA104S-X DIGI TRANSISTOR
Q402 KRC107S-X DIGI TRANSISTOR
Q403 KRC107S-X DIGI TRANSISTOR
Q1131 IMX9-W TRANSISTOR Driver
Q1133 IMX9-W TRANSISTOR Driver
Q1135 IMX9-W TRANSISTOR Driver
Q1137 2SC3661-X TRANSISTOR
Q1251 KRA104S-X DIGI TRANSISTOR
Q1252 KRA104S-X DIGI TRANSISTOR
Q2501 KRA104S-X DIGI TRANSISTOR
Q2502 KRC107S-X DIGI TRANSISTOR
Q2521 IMX9-W TRANSISTOR Driver
Q2561 IMX9-W TRANSISTOR Driver
Q2581 IMX9-W TRANSISTOR Driver
D401 MA152WK-X SI DIODE
D403 MA152WK-X SI DIODE
D405 MA152WK-X SI DIODE
D406 DAP202K-X D.TRANSISTOR
C401 NCB31HK-102X C CAPACITOR 1000pF 50V K
C402 NCB31HK-102X C CAPACITOR 1000pF 50V K
C403 NEA70JM-476X E CAPACITOR 47uF 6.3V M
C404 NEA70JM-476X E CAPACITOR 47uF 6.3V M
C405 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C406 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C407 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C408 NEA70JM-476X E CAPACITOR 47uF 6.3V M
C411 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C413 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C421 NEA70JM-107X E CAPACITOR 100uF 6.3V M
C422 NCB31CK-103X C CAPACITOR 0.01uF 16V K
C423 NDC31HJ-101X C CAPACITOR 100pF 50V J
C424 NCS31HJ-121X C CAPACITOR 120pF 50V J
C425 NCB31AK-474X C CAPACITOR 0.47uF 10V K
C426 NCB31CK-103X C CAPACITOR 0.01uF 16V K
C427 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C428 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C429 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C430 NCB31CK-473X C CAPACITOR 0.047uF 16V K
C431 NDC31HJ-180X C CAPACITOR 18pF 50V J
C432 NDC31HJ-220X C CAPACITOR 22pF 50V J
C433 NCB31CK-103X C CAPACITOR 0.01uF 16V K
C434 NEA70JM-107X E CAPACITOR 100uF 6.3V M
C435 NCB31CK-103X C CAPACITOR 0.01uF 16V K
C436 NEA70JM-476X E CAPACITOR 47uF 6.3V M
C437 NCB31CK-103X C CAPACITOR 0.01uF 16V K
C442 NDC31HJ-101X C CAPACITOR 100pF 50V J
C443 NDC31HJ-101X C CAPACITOR 100pF 50V J
C444 NCB31CK-103X C CAPACITOR 0.01uF 16V K
C445 NEA70JM-107X E CAPACITOR 100uF 6.3V M
C450 NCS31HJ-471X C CAPACITOR 470pF 50V J
C451 NCB31CK-103X C CAPACITOR 0.01uF 16V K
C452 NEA70JM-107X E CAPACITOR 100uF 6.3V M
C453 NEA70JM-107X E CAPACITOR 100uF 6.3V M
C454 NCB31CK-103X C CAPACITOR 0.01uF 16V K
C455 NEA70JM-107X E CAPACITOR 100uF 6.3V M
C456 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C458 NCB31CK-103X C CAPACITOR 0.01uF 16V K
C459 NCB31CK-103X C CAPACITOR 0.01uF 16V K
C460 NEA71CM-476X E CAPACITOR 47uF 16V M
C461 NEA71CM-476X E CAPACITOR 47uF 16V M
C462 NCB31CK-103X C CAPACITOR 0.01uF 16V K
C463 NEA70JM-107X E CAPACITOR 100uF 6.3V M
C466 NEA71CM-476X E CAPACITOR 47uF 16V M
C467 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z
C493 NCB30JK-105X C CAPACITOR 1uF 6.3V K
C494 NCB31CK-103X C CAPACITOR 0.01uF 16V K
C495 NCB31CK-103X C CAPACITOR 0.01uF 16V K
C1101 NCB31HK-331X C CAPACITOR 330pF 50V K
C1102 NCB31HK-331X C CAPACITOR 330pF 50V K
C1103 NEA71EM-475X E CAPACITOR 4.7uF 25V M
C1104 NEA71EM-475X E CAPACITOR 4.7uF 25V M
C1121 NCB31CK-223X C CAPACITOR 0.022uF 16V K
C1122 NCB31HK-822X C CAPACITOR 8200pF 50V K
C1123 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C1124 NCB21CK-224X C CAPACITOR 0.22uF 16V K
C1125 NCB31CK-223X C CAPACITOR 0.022uF 16V K
C1126 NCB31CK-223X C CAPACITOR 0.022uF 16V K
C1127 NEA71EM-475X E CAPACITOR 4.7uF 25V M
C1128 NEA71EM-475X E CAPACITOR 4.7uF 25V M
C1129 NCB31HK-822X C CAPACITOR 8200pF 50V K
C1130 NCB21CK-224X C CAPACITOR 0.22uF 16V K
C1131 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C1141 NEA71CM-476X E CAPACITOR 47uF 16V M
C1142 NEA71CM-476X E CAPACITOR 47uF 16V M
C1176 NCB31CK-103X C CAPACITOR 0.01uF 16V K
C1177 NCB31CK-103X C CAPACITOR 0.01uF 16V K
C1178 NCB31CK-103X C CAPACITOR 0.01uF 16V K
C1179 NCB31CK-103X C CAPACITOR 0.01uF 16V K
C1180 NCB31CK-103X C CAPACITOR 0.01uF 16V K
C1181 NCB31CK-103X C CAPACITOR 0.01uF 16V K
C1183 NEA71EM-475X E CAPACITOR 4.7uF 25V M
C1201 NEA71EM-475X E CAPACITOR 4.7uF 25V M
C1202 NEA71EM-475X E CAPACITOR 4.7uF 25V M
C1203 NEA71EM-475X E CAPACITOR 4.7uF 25V M
C1204 NEA71EM-475X E CAPACITOR 4.7uF 25V M
C1205 NEA71EM-475X E CAPACITOR 4.7uF 25V M
C1206 NEA71EM-475X E CAPACITOR 4.7uF 25V M
C1207 NEA71EM-475X E CAPACITOR 4.7uF 25V M
C1208 NEA71EM-475X E CAPACITOR 4.7uF 25V M
C1209 NEA71EM-475X E CAPACITOR 4.7uF 25V M
C1210 NEA71EM-475X E CAPACITOR 4.7uF 25V M
C1211 NEA71EM-475X E CAPACITOR 4.7uF 25V M
C1212 NEA71EM-475X E CAPACITOR 4.7uF 25V M
C1213 NEA71EM-475X E CAPACITOR 4.7uF 25V M
C1214 NEA71EM-475X E CAPACITOR 4.7uF 25V M
C1215 NEA71EM-475X E CAPACITOR 4.7uF 25V M
C1216 NEA71EM-475X E CAPACITOR 4.7uF 25V M
C1217 NEA71EM-475X E CAPACITOR 4.7uF 25V M
C1218 NEA71EM-475X E CAPACITOR 4.7uF 25V M
C1221 NDC31HJ-470X C CAPACITOR 47pF 50V J
C1222 NDC31HJ-470X C CAPACITOR 47pF 50V J
C1223 NDC31HJ-470X C CAPACITOR 47pF 50V J
C1224 NDC31HJ-470X C CAPACITOR 47pF 50V J
C1225 NCS31HJ-471X C CAPACITOR 470pF 50V J
C1226 NDC31HJ-470X C CAPACITOR 47pF 50V J
C1227 NCB31HK-471X C CAPACITOR 470pF 50V K
C1228 NCB31HK-471X C CAPACITOR 470pF 50V K
C1251 NCB31CK-103X C CAPACITOR 0.01uF 16V K
C1252 NCB31CK-103X C CAPACITOR 0.01uF 16V K
C2503 NEA71EM-475X E CAPACITOR 4.7uF 25V M
 Symbol No. Part No. Part Name Description Local
