JVC TH M45 Service Manual

3-15
Mother board
Block No. [0][4][0][0]
R1166 NRSA63J-104X MG RESISTOR 100k Ω 1/16W J
R1167 NRSA63J-332X MG RESISTOR 3.3k Ω 1/16W J
R1168 NRSA63J-332X MG RESISTOR 3.3k Ω 1/16W J
R1169 NRSA63J-393X MG RESISTOR 39k Ω 1/16W J
R1170 NRSA63J-393X MG RESISTOR 39k Ω 1/16W J
R1171 NRSA63J-332X MG RESISTOR 3.3k
Ω 1/16W J
R1172 NRSA63J-332X MG RESISTOR 3.3k
Ω 1/16W J
R1173 NRSA63J-473X MG RESISTOR 47k Ω 1/16W J
R1174 NRSA63J-473X MG RESISTOR 47k Ω 1/16W J
R1175 NRSA63J-332X MG RESISTOR 3.3k Ω 1/16W J
R1176 NRSA63J-393X MG RESISTOR 39k Ω 1/16W J
R1197 NRSA63J-474X MG RESISTOR 470k Ω 1/16W J
R1201 NRSA63J-124X MG RESISTOR 120k Ω 1/16W J
R1202 NRSA63J-124X MG RESISTOR 120k Ω 1/16W J
R1251 NRSA63J-223X MG RESISTOR 22k Ω 1/16W J
R1252 NRSA63J-223X MG RESISTOR 22k Ω 1/16W J
R2501 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R2502 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R2503 NRSA63J-513X MG RESISTOR 51k Ω 1/16W J
R2504 NRSA63J-513X MG RESISTOR 51k Ω 1/16W J
R2507 NRSA63J-103X MG RESISTOR 10k
Ω 1/16W J
R2508 NRSA63J-103X MG RESISTOR 10k
Ω 1/16W J
R2509 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R2510 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R2513 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R2514 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R2515 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R2516 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R2517 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R2518 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R2519 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R2520 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R2525 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R2526 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R2527 NRSA63J-104X MG RESISTOR 100k Ω 1/16W J
R2528 NRSA63J-104X MG RESISTOR 100k Ω 1/16W J
R2529 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R2530 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R2531 NRSA63J-104X MG RESISTOR 100k Ω 1/16W J
R2532 NRSA63J-104X MG RESISTOR 100k Ω 1/16W J
R2533 NRSA63J-223X MG RESISTOR 22k Ω 1/16W J
R2534 NRSA63J-223X MG RESISTOR 22k Ω 1/16W J
R2535 NRSA63J-563X MG RESISTOR 56k Ω 1/16W J
R2536 NRSA63J-563X MG RESISTOR 56k Ω 1/16W J
R2537 NRSA63J-104X MG RESISTOR 100k Ω 1/16W J
R2538 NRSA63J-104X MG RESISTOR 100k Ω 1/16W J
R2561 NRSA63J-104X MG RESISTOR 100k Ω 1/16W J
R2562 NRSA63J-104X MG RESISTOR 100k Ω 1/16W J
R2563 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R2564 NRSA63J-103X MG RESISTOR 10k
Ω 1/16W J
R2565 NRSA63J-392X MG RESISTOR 3.9k Ω 1/16W J
R2566 NRSA63J-392X MG RESISTOR 3.9k
Ω 1/16W J
R2567 NRSA63J-103X MG RESISTOR 10k
Ω 1/16W J
R2568 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R2575 NRSA63J-102X MG RESISTOR 1k
Ω 1/16W J
R2576 NRSA63J-102X MG RESISTOR 1k
Ω 1/16W J
R2577 NRSA63J-104X MG RESISTOR 100k Ω 1/16W J
R2578 NRSA63J-104X MG RESISTOR 100k
Ω 1/16W J
R2579 NRSA63J-104X MG RESISTOR 100k Ω 1/16W J
R2580 NRSA63J-104X MG RESISTOR 100k
Ω 1/16W J
R2581 NRSA63J-104X MG RESISTOR 100k
Ω 1/16W J
R2582 NRSA63J-104X MG RESISTOR 100k Ω 1/16W J
R2583 NRSA63J-103X MG RESISTOR 10k
Ω 1/16W J
R2584 NRSA63J-124X MG RESISTOR 120k
Ω 1/16W J
R2585 NRSA63J-392X MG RESISTOR 3.9k Ω 1/16W J
R2586 NRSA63J-123X MG RESISTOR 12k
Ω 1/16W J
R2587 NRSA63J-103X MG RESISTOR 10k
Ω 1/16W J
R2588 NRSA63J-103X MG RESISTOR 10k
Ω 1/16W J
R2590 NRSA63J-333X MG RESISTOR 33k
Ω 1/16W J
R2592 NRSA63J-333X MG RESISTOR 33k Ω 1/16W J
R2594 NRSA63J-333X MG RESISTOR 33k
Ω 1/16W J
R2595 NRSA63J-102X MG RESISTOR 1k
Ω 1/16W J
R2596 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R2597 NRSA63J-104X MG RESISTOR 100k
Ω 1/16W J
R2598 NRSA63J-104X MG RESISTOR 100k
Ω 1/16W J
R2599 NRSA63J-104X MG RESISTOR 100k Ω 1/16W J
R2600 NRSA63J-104X MG RESISTOR 100k
Ω 1/16W J
 Symbol No. Part No. Part Name Description Local
CN401 QGF1016F2-31W CONNECTOR FFC/FPC (1-31)
J1101 QNN0598-001 PIN JACK
J1103 QND0118-001 DIN CONNECTOR
K401 NQR0319-001X FERRITE BEADS
LC401 NQR0321-001X EMI FILTER
X401 NAX0385-001X CRYSTAL 24.576MHz
X402 NAX0275-001X C OSCILLATOR 6.144MHz
 Symbol No. Part No. Part Name Description Local
 Q151 KTC3203/OY/-T TRANSISTOR
Q501 KRA104M-T DIGI TRANSISTOR
Q502 KRC102M-T DIGI TRANSISTOR
Q503 KTC3199/GL/-T TRANSISTOR
Q504 KTA1267/YG/-T TRANSISTOR
Q505 KRC102M-T DIGI TRANSISTOR
Q511 KRC104M-T TRANSISTOR
Q512 KTC3199/GL/-T TRANSISTOR
Q513 KTC3199/GL/-T TRANSISTOR
Q514 KRA102M-T DIGI TRANSISTOR
Q515 KTC3203/OY/-T TRANSISTOR
Q516 KTC3199/GL/-T TRANSISTOR
Q517 KRC104M-T TRANSISTOR
Q521 KRA104M-T DIGI TRANSISTOR
Q522 KTC3199/GL/-T TRANSISTOR
Q523 KTC3199/GL/-T TRANSISTOR
Q524 KTA1267/YG/-T TRANSISTOR
Q525 KTC3199/GL/-T TRANSISTOR
Q531 KTC3199/GL/-T TRANSISTOR
Q532 KTC3199/GL/-T TRANSISTOR
Q545 KRC102M-T DIGI TRANSISTOR
D101 1SS133-T2 DIODE
 D151 GBU803 BRIDGE DIODE
 D152 GBU803 BRIDGE DIODE
D153 1SS133-T2 DIODE
D154 1SS133-T2 DIODE
D161 1SS133-T2 DIODE
D162 MTZJ13C-T2 Z DIODE
D401 11ES2-T4 DIODE
D402 1SS133-T2 DIODE
D403 MTZJ6.2B-T2 Z DIODE
D501 1SS133-T2 DIODE
D502 1SS133-T2 DIODE
D503 MTZJ5.1C-T2 Z DIODE
D504 1SS133-T2 DIODE
D505 1SS133-T2 DIODE
D511 1SS133-T2 DIODE
D512 1SS133-T2 DIODE
D513 1SS133-T2 DIODE
D514 1SS133-T2 DIODE
D515 MTZJ15C-T2 Z DIODE
D516 1SS133-T2 DIODE
D517 MTZJ27B-T2 Z DIODE
D518 MTZJ27B-T2 Z DIODE
D519 1SS133-T2 DIODE
D520 MTZJ3.6A-T2 ZENER DIODE
D521 1SS133-T2 DIODE
D522 1SS133-T2 DIODE
D523 1SS133-T2 DIODE
D524 1SS133-T2 DIODE
D525 MTZJ15C-T2 Z DIODE
D526 MTZJ6.2B-T2 Z DIODE
D535 1SS133-T2 DIODE
 C101 QCZ9105-472 C CAPACITOR 4700pF 250V M
C151 QFLC2AJ-104Z M CAPACITOR 0.1uF 100V J
C152 QFLC2AJ-104Z M CAPACITOR 0.1uF 100V J
C153 QFLC2AJ-104Z M CAPACITOR 0.1uF 100V J
C154 QFLC2AJ-104Z M CAPACITOR 0.1uF 100V J
C155 QFLC2AJ-104Z M CAPACITOR 0.1uF 100V J
 Symbol No. Part No. Part Name Description Local
