JVC TH M45 Service Manual

1-2 (No.MB067)
SPECIFICATION
Center unit (XV-THM42)
Audio section
Total Harmonic Distortion 0.02%
NOTE: This value is measured at System cord CONNECTOR for reference.
Audio input sensitivity/
Impedance (at 1 kHz)
Analog input AUDIO IN (VCR) 290 mV/47 kΩ
Digital input* DIGITAL IN (DBS) (OPTICAL) -21 dBm to -15 dBm (660 nm ±30 nm)
* Corresponding to Linear PCM, Dolby Digital, and DTS Digital Surround (with sampling frequency - 32 kHz, 44.1
kHz, 48 kHz)
Video section
Color System NTSC
Horizontal Resolution 500 lines
Signal-to-Noise Ratio 64 dB
Video output level Composite 1.0 V(p-p)/75 Ω
S-video-Y 1.0 V(p-p)/75 Ω
S-video-C 0.286 V(p-p)/75 Ω
Component-Y 1.0 V(p-p)/75 Ω
Component-PB/PR 0.7 V(p-p)/75 Ω
Video input sensitivity/
Impedance (VCR IN)
Composite 1.0 V(p-p)/75 Ω
S-video-Y 1.0 V(p-p)/75 Ω
S-video-C 0.286 V(p-p)/75 Ω
Tuner section
Tuning Range FM 87.5 MHz to 108.0 MHz
AM 530 kHz to 1710 kHz
General
Power Requirements AC 120 V, 60 Hz
Power Consumption 20 W (at operation), 1.0 W (in standby mode)
Dimensions (W × H × D) 400 mm × 85 mm × 386 mm (15-3/4 inches × 3-3/8 inches × 15-1/14 inches)
Mass 4.6 kg (10.2 lbs)
Subwoofer (SP-PWM45)
Amplifier section
Front/Center/Surround 80 W per channel, RMS at 6 Ω (Center/Surround)/80 W per channel, RMS at 4 Ω (Front) at 1 kHz, with 10 % total
harmonic distortion.
Subwoofer 120 W, RMS at 4 Ω at 100 Hz, with 10 % total harmonic distortion.
Speaker section
Speaker unit 16 cm (6-5/16 inches) Bass-reflex, Magnetically Shielded
Frequency Range 30 Hz to 200 Hz
General
Power Requirements AC 120 V, 60 Hz
Power Consumption 140 W (at operation), 0 W (in standby mode)
Dimensions (W × H × D) 216 mm × 353 mm × 485 mm (8-9/16 inches × 13-15/16 inches × 19-1/8 inches)
Mass 12.0 kg (26.5 lbs)
Satellite Speakers
Front speakers (SP-THM45F)
Speakers 8.0 cm (3-3/16 inches), Bass-reflex, Magnetically Shielded
Power Handling Capacity 120 W
Impedance 4 Ω
Frequency Range 90 Hz to 20 kHz
Dimensions (W × H × D) 103 mm × 115 mm × 100 mm (4-1/16 inches × 4-9/16 inches × 3-15/16 inches)
Mass 0.64 kg (1.5 lbs)
Surround speakers (SP-THM45S)
Speakers 8.0 cm (3-3/16 inches), Bass-reflex, Magnetically Shielded
Power Handling Capacity 80 W
Impedance 6 Ω
Frequency Range 90 Hz to 20 kHz
Dimensions (W × H × D) 103 mm × 115 mm × 100 mm (4-1/16 inches × 4-9/16 inches × 3-15/16 inches)
Mass 0.52 kg (1.2 lbs)
Center Speaker (SP-THM45C)
Speakers 8.0 cm (3-3/16 inches), Bass-reflex, Magnetically Shielded
Power Handling Capacity 80 W
Impedance 6 Ω
Frequency Range 90 Hz to 20 kHz
Dimensions (W × H × D) 103 mm × 115 mm × 100 mm (4-1/16 inches × 4-9/16 inches × 3-15/16 inches)
Mass 0.64 kg (1.5 lbs)
Accessories
Remote control (1), Batteries (2), FM antenna (1), AM loop antenna (1), Power cord (1), System cord (1), Composite video cord (1)
Speaker codes
5 m (16 ft) For satellite (front left/right) and center speakers (3)
10 m (32 ft) For satellite speakers (surround left/right) (2) (The length of the above speaker cords are approximate.)
