(No.MB512)1-19
3.2.3
Removing the feed motor ass
embly
(See Fig.13
)
(1)
Remove the one screw
G
attaching the feed
motor assem-
bly.
(2)
Remove the feed motor wires from solder p
art of spindle
motor board.
Fig.13
3.2.4
Removing the spindle
motor assembly
(See Fig.14
)
(1)
Remove the two screws
H
attaching th
e spindle mo
tor from
spindle motor board.
Fig.14
Lead screw
Middle gear
Splder part
G
Spindle motor
H
27
29
Table of Contents
Service Manual
10
Table of Contents
10
Precaution
13
Specific Service Instructions
16
Disassembly
17
Adjustment
30
Troubleshooting
33
Parts List
52
Speaker Assembly and Parts List(Subwoofer) (Block No.m2)
57
DVD Mechanism Assembly and Parts List (Block No.mj)
58
DVD Loading Base Assembly and Parts List (Block No.mn)
60
Electrical Parts List (Block No.01~04)
62
Packing Materials and Accessories Parts List (Except TH-P3UJ) (Block No.m3)
71
Packing Materials and Accessories Parts List (Only TH-P3UJ) (Block No.m4)
73
4
