1-8 (No.MB512)
SECTION 3
DISASSEMBLY
3.1
Main body
3.1.1
Removing the top cover
(See Fig.1 and 2)
(1)
Remove the two screws
A
attach
ing the top cover of both
side. (See Fig.1)
(2)
Remove the five screws
B
attaching the top cover of rear
side. (See Fig.2)
Fig.1
Fig.2
A
B
16
18
Table of Contents
Service Manual
10
Table of Contents
10
Precaution
13
Specific Service Instructions
16
Disassembly
17
Adjustment
30
Troubleshooting
33
Parts List
52
Speaker Assembly and Parts List(Subwoofer) (Block No.m2)
57
DVD Mechanism Assembly and Parts List (Block No.mj)
58
DVD Loading Base Assembly and Parts List (Block No.mn)
60
Electrical Parts List (Block No.01~04)
62
Packing Materials and Accessories Parts List (Except TH-P3UJ) (Block No.m3)
71
Packing Materials and Accessories Parts List (Only TH-P3UJ) (Block No.m4)
73
