JVC TH-P3A User Manual

3-11
Electrical parts list
Main board
Block No. [0][1]
 Symbol No. Part No. Part Name Description Local
IC102 TAS5086DBT-X IC
IC103 TAS5142DDV-X IC
IC104 TAS5142DDV-X IC
IC105 RC4580ID-X IC
IC108 RC4558D-X IC
IC109 IMX9-W TRANSISTOR
IC461 AK5358ET-X IC
IC471 MN101C49GPT1 IC MASK
IC472 S-80840CNNB-G-W IC
IC473 SN74AHCT08NS-X IC
IC477 BR24L08F-W-X IC(DIGITAL)
IC491 KIA7805API IC
IC492 MM1593DF-X IC
IC493 LB1641 IC
IC494 KIA78S09P-T IC
Q1001 KRA102S-X DIGI TRANSISTOR
Q1002 RJK005N03-X MOS FET
Q1003 RJK005N03-X MOS FET
Q1101 KTA1504/YG/-X TRANSISTOR
Q1103 KTC3875/YG/-X TRANSISTOR
Q1201 KTA1504/YG/-X TRANSISTOR
Q1203 KTC3875/YG/-X TRANSISTOR
Q1303 KTC3875/YG/-X TRANSISTOR
Q1403 KTC3875/YG/-X TRANSISTOR
Q1503 KTC3875/YG/-X TRANSISTOR
Q1603 KTC3875/YG/-X TRANSISTOR
Q1701 KTC3875/YG/-X TRANSISTOR
Q1702 KTC3875/YG/-X TRANSISTOR
Q1703 KTA1504/YG/-X TRANSISTOR
Q1704 KTC3875/YG/-X TRANSISTOR
Q4201 KRC103S-X DIGITAL TR
Q4202 KRA102S-X DIGI TRANSISTOR
Q4203 KTC3203/OY/-T TRANSISTOR
Q4601 KRC110S-X DIGI TRANSISTOR
Q4831 KRC102S-X DIGI TRANSISTOR
Q4832 KTC3875/YG/-X TRANSISTOR
D1001 RB521S-30-X SB DIODE
D1002 RB521S-30-X SB DIODE
D1101 1SS355W-X DIODE
D1201 1SS355W-X DIODE
D1301 1SS355W-X DIODE
D1401 1SS355W-X DIODE
D1501 1SS355W-X DIODE
D1601 1SS355W-X DIODE
D4201 UDZW10B-X Z DIODE
D4831 MA152WA-X DIODE
D4832 1SS355W-X DIODE
D4835 UDZW6.8B-X Z DIODE
D4836 MA152WA-X DIODE
D4838 1SS355W-X DIODE
D4840 1SS355W-X DIODE
D4841 1SS355W-X DIODE
D4842 MA152WA-X DIODE
D4843 ER204-F33 FR DIODE
D4845 1SS355W-X DIODE
D4846 ER204-F33 FR DIODE
D4848 1SS355W-X DIODE
D4962 1N4003S-T5 SI DIODE
D4966 UDZW4.7B-X Z DIODE
C1002 NCB31CK-224X C CAPACITOR 0.22uF 16V K
C1003 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C1004 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C1005 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C1006 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C1007 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C1008 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C1009 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C1010 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C1011 QETN1CM-107Z E CAPACITOR 100uF 16V M
C1012 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C1013 QETN1HM-226Z E CAPACITOR 22uF 50V M
C1014 NCB31HK-104X C CAPACITOR 0.1uF 50V K
C1015 QETN1HM-226Z E CAPACITOR 22uF 50V M
C1016 NCB31HK-104X C CAPACITOR 0.1uF 50V K
C1017 NCB31HK-104X C CAPACITOR 0.1uF 50V K
C1018 NCB31HK-104X C CAPACITOR 0.1uF 50V K
C1019 QFVF1HJ-105Z MF CAPACITOR 1uF 50V J
C1020 QETM1HM-228 E CAPACITOR 2200uF 50V M
C1021 NCB31HK-104X C CAPACITOR 0.1uF 50V K
C1022 QETN1CM-107Z E CAPACITOR 100uF 16V M
C1023 NCB31CK-105X C CAPACITOR 1uF 16V K
C1024 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C1028 NCB31HK-104X C CAPACITOR 0.1uF 50V K
C1029 NCB31HK-104X C CAPACITOR 0.1uF 50V K
C1030 QETN1EM-476Z E CAPACITOR 47uF 25V M
C1031 NCB21CK-104X C CAPACITOR 0.1uF 16V K
C1034 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C1035 NDC31HJ-150X C CAPACITOR 15pF 50V J
C1037 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C1040 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C1041 NCB31HK-104X C CAPACITOR 0.1uF 50V K
C1101 NCB31HK-104X C CAPACITOR 0.1uF 50V K
C1102 NCB31HK-333X C CAPACITOR 0.033uF 50V K
C1103 NCB31HK-681X C CAPACITOR 680pF 50V K
C1104 NCB31HK-681X C CAPACITOR 680pF 50V K
C1105 QETN1VM-477Z E CAPACITOR 470uF 35V M
C1106 QETN1VM-477Z E CAPACITOR 470uF 35V M
C1107 QFVF1HJ-105Z MF CAPACITOR 1uF 50V J
C1108 NCB31HK-472X C CAPACITOR 4700pF 50V K
C1109 NCB31HK-472X C CAPACITOR 4700pF 50V K
C1110 NCB31HK-472X C CAPACITOR 4700pF 50V K
C1111 NCB31HK-472X C CAPACITOR 4700pF 50V K
C1112 NCB31HK-473X C CAPACITOR 0.047uF 50V K
C1113 NCB31HK-473X C CAPACITOR 0.047uF 50V K
C1114 NCB31HK-271X C CAPACITOR 270pF 50V K
C1115 NCB31HK-271X C CAPACITOR 270pF 50V K
C1116 NCB31HK-223X C CAPACITOR 0.022uF 50V K
C1117 QFVF1HJ-224Z MF CAPACITOR 0.22uF 50V J
C1118 NDC31HJ-271X C CAPACITOR 270pF 50V J
C1119 NDC31HJ-560X C CAPACITOR 56pF 50V J
C1120 NCB31HK-152X C CAPACITOR 1500pF 50V K
C1121 QETN1CM-227Z E CAPACITOR 220uF 16V M
C1123 NCB31HK-104X C CAPACITOR 0.1uF 50V K
C1124 QETN1HM-106Z E CAPACITOR 10uF 50V M
C1125 NCB31HK-104X C CAPACITOR 0.1uF 50V K
C1126 NCF21HZ-474X C CAPACITOR 0.47uF 50V Z
C1127 NCB31HK-104X C CAPACITOR 0.1uF 50V K
C1201 NCB31HK-104X C CAPACITOR 0.1uF 50V K
C1202 NCB31HK-333X C CAPACITOR 0.033uF 50V K
C1203 NCB31HK-681X C CAPACITOR 680pF 50V K
C1204 NCB31HK-681X C CAPACITOR 680pF 50V K
C1205 QETN1VM-477Z E CAPACITOR 470uF 35V M
C1206 QETN1VM-477Z E CAPACITOR 470uF 35V M
C1207 QFVF1HJ-105Z MF CAPACITOR 1uF 50V J
C1208 NCB31HK-472X C CAPACITOR 4700pF 50V K
C1209 NCB31HK-472X C CAPACITOR 4700pF 50V K
C1210 NCB31HK-472X C CAPACITOR 4700pF 50V K
C1211 NCB31HK-472X C CAPACITOR 4700pF 50V K
C1212 NCB31HK-473X C CAPACITOR 0.047uF 50V K
C1213 NCB31HK-473X C CAPACITOR 0.047uF 50V K
C1214 NCB31HK-271X C CAPACITOR 270pF 50V K
C1215 NCB31HK-271X C CAPACITOR 270pF 50V K
C1216 NCB31HK-223X C CAPACITOR 0.022uF 50V K
C1217 QFVF1HJ-224Z MF CAPACITOR 0.22uF 50V J
C1218 NDC31HJ-271X C CAPACITOR 270pF 50V J
C1219 NDC31HJ-560X C CAPACITOR 56pF 50V J
C1220 NCB31HK-152X C CAPACITOR 1500pF 50V K
C1221 QETN1CM-227Z E CAPACITOR 220uF 16V M
C1223 NCB31HK-104X C CAPACITOR 0.1uF 50V K
C1224 QETN1HM-106Z E CAPACITOR 10uF 50V M
C1225 NCB31HK-104X C CAPACITOR 0.1uF 50V K
C1226 NCF21HZ-474X C CAPACITOR 0.47uF 50V Z
C1227 NCB31HK-104X C CAPACITOR 0.1uF 50V K
C1301 NCB31HK-104X C CAPACITOR 0.1uF 50V K
C1302 NCB31HK-104X C CAPACITOR 0.1uF 50V K
 Symbol No. Part No. Part Name Description Local
