JVC TH-P3A

SCHEMATIC DIAGRAMS
TH-P3A,TH-P3US,TH-P3UB
TH-P3UW,TH-P3UX,TH-P3UY
TH-P3UJ,TH-P3UG,TH-P3UN
Contents
Block diagram
Standard schematic diagrams
Printed circuit boards
2-1
2-2
2-10 to 12
CD-ROM No.SML200607
DVD DIGITAL CINEMA SYSTEM
No.MB541SCH
2006/7
COPYRIGHT 2006 Victor Company of Japan, Limited.
Lead free solder used in the board (material : Sn-Ag-Cu, melting point : 219 Centigrade)
XV-THP3
SP-THP3F SP-THP3F
SP-THP3C SP-THP3SSP-THP3S
SP-WP5
