JVC TH-P3A User Manual

3-14
Power board
Block No. [0][2]
R4606 NRSA63J-101X MG RESISTOR 100 Ω 1/16W J
R4607 NRSA63J-562X MG RESISTOR 5.6k Ω 1/16W J
R4608 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R4701 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
R4702 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R4705 NRSA63J-223X MG RESISTOR 22k
Ω 1/16W J
R4706 NRSA63J-221X MG RESISTOR 220
Ω 1/16W J
R4707 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R4708 NRSA63J-221X MG RESISTOR 220 Ω 1/16W J
R4709 NRSA63J-101X MG RESISTOR 100 Ω 1/16W J
R4710 NRSA63J-104X MG RESISTOR 100k Ω 1/16W J
R4711 NRSA63J-331X MG RESISTOR 330 Ω 1/16W J
R4712 NRSA63J-331X MG RESISTOR 330 Ω 1/16W J
R4713 NRSA63J-331X MG RESISTOR 330 Ω 1/16W J
R4716 NRSA63J-222X MG RESISTOR 2.2k Ω 1/16W J
R4717 NRSA63J-472X MG RESISTOR 4.7k Ω 1/16W J
R4718 NRSA63J-472X MG RESISTOR 4.7k Ω 1/16W J
R4751 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
A,US,UB,UX,
UY,UG,UN
R4752 NRSA63J-273X MG RESISTOR 27k Ω 1/16W J
A,US,UB,UJ,
UG,UN
R4752 NRSA63J-153X MG RESISTOR 15k Ω 1/16W J UW,UY
R4752 NRSA63J-822X MG RESISTOR 8.2k
Ω 1/16W J UX
R4753 NRSA63J-103X MG RESISTOR 10k
Ω 1/16W J
R4754 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R4755 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R4756 NRSA63J-153X MG RESISTOR 15k Ω 1/16W J
R4757 NRSA63J-153X MG RESISTOR 15k Ω 1/16W J
R4760 NRSA63J-222X MG RESISTOR 2.2k Ω 1/16W J
R4761 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R4762 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R4764 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R4765 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R4771 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R4772 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R4773 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R4774 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J UW,UJ
R4775 NRSA63J-331X MG RESISTOR 330 Ω 1/16W J
R4776 NRSA63J-331X MG RESISTOR 330 Ω 1/16W J
R4777 NRSA63J-101X MG RESISTOR 100 Ω 1/16W J
R4778 NRSA63J-101X MG RESISTOR 100 Ω 1/16W J
R4779 NRSA63J-331X MG RESISTOR 330 Ω 1/16W J
R4780 NRSA63J-331X MG RESISTOR 330 Ω 1/16W J
R4781 NRSA63J-331X MG RESISTOR 330 Ω 1/16W J
R4782 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
R4791 NRSA02J-221X MG RESISTOR 220 Ω 1/10W J
R4833 NRSA63J-562X MG RESISTOR 5.6k Ω 1/16W J
R4834 NRSA63J-473X MG RESISTOR 47k Ω 1/16W J
R4835 NRSA63J-472X MG RESISTOR 4.7k
Ω 1/16W J
R4842 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R4843 NRSA63J-103X MG RESISTOR 10k
Ω 1/16W J
R4844 NRSA63J-103X MG RESISTOR 10k
Ω 1/16W J
R4845 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R4846 NRSA63J-103X MG RESISTOR 10k
Ω 1/16W J
R4847 NRSA63J-103X MG RESISTOR 10k
Ω 1/16W J
R4848 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R4861 NRSA63J-222X MG RESISTOR 2.2k
Ω 1/16W J
R4863 NRSA63J-222X MG RESISTOR 2.2k Ω 1/16W J
R4864 NRSA63J-331X MG RESISTOR 330
Ω 1/16W J
R4866 NRSA63J-272X MG RESISTOR 2.7k
Ω 1/16W J
R4871 NRSA63J-331X MG RESISTOR 330 Ω 1/16W J
R4872 NRSA63J-331X MG RESISTOR 330
Ω 1/16W J
R4873 NRSA63J-331X MG RESISTOR 330
Ω 1/16W J
R4875 NRSA63J-471X MG RESISTOR 470 Ω 1/16W J
R4876 NRSA63J-331X MG RESISTOR 330
Ω 1/16W J
R4877 NRSA63J-471X MG RESISTOR 470
Ω 1/16W J
R4881 NRSA63J-472X MG RESISTOR 4.7k Ω 1/16W J
R4883 NRSA63J-472X MG RESISTOR 4.7k Ω 1/16W J
R4886 NRSA63J-562X MG RESISTOR 5.6k Ω 1/16W J
R4887 NRSA63J-103X MG RESISTOR 10k
Ω 1/16W J
R4894 NRSA63J-331X MG RESISTOR 330
Ω 1/16W J
R4901 QRT017J-2R2 MF RESISTOR 2.2 Ω 1W J
R4902 NRSA63J-822X MG RESISTOR 8.2k
Ω 1/16W J
R4903 NRSA63J-103X MG RESISTOR 10k
Ω 1/16W J
R4904 QRL027J-101 OMF RESISTOR 100 Ω 2W J
L1101 QQR1699-001 CHOKE COIL
L1201 QQR1699-001 CHOKE COIL
 Symbol No. Part No. Part Name Description Local
L1301 QQR1699-001 CHOKE COIL
L1302 QQR1699-001 CHOKE COIL
L1401 QQR1699-001 CHOKE COIL
L1501 QQR1699-001 CHOKE COIL
L1601 QQR1699-001 CHOKE COIL
L1602 QQR1699-001 CHOKE COIL
CN101 QGD2501C1-04Z CONNECTOR (1-4)
CN401 QGD2501C1-07Z CONNECTOR (1-7)
CN403 QGD2501C1-07Z CONNECTOR (1-7)
CN404 QGD2501C1-06Z CONNECTOR (1-6)
CN405 QGF1036C2-05 CONNECTOR FFC/FPC (1-5)
CN406 QGF1205C2-05 CONNECTOR FFC/FPC (1-5)
CN407 QGF1036C2-15 CONNECTOR FFC/FPC (1-15)
CN408 QGF1036C2-21 CONNECTOR FFC/FPC (1-21)
CN411 QGF1036C2-25 CONNECTOR FFC/FPC (1-25)
CN412 QGF1036C2-15 CONNECTOR FFC/FPC (1-15)
CN413 QGF1036C2-05 CONNECTOR FFC/FPC (1-5)
CN414 QGA1002C1-03X CONNECTOR W-B (1-3)
CN417 QGA2501C1-03 CONNECTOR W-B (1-3)
CN421 QGF1205C2-13 CONNECTOR FFC/FPC (1-13)
CN422 QGD2501C1-05Z CONNECTOR (1-5)
CN801 WJP0079-001A-E E-SH C WIRE C-B
 CP471 ICP-N5-T IC PROTECTOR 250mA
J1001 QNB0189-001 SPEAKER TERMINA
J8001 QNZ0851-001 USB CONNECTOR
K1001 NQR0502-001X FERRITE BEADS
K1002 NQR0502-001X FERRITE BEADS
K4702 QQR0621-001Z COIL
K8001 NQR0502-001X FERRITE BEADS
K8002 NQR0022-002X FERRITE BEADS
K8003 NQR0022-002X FERRITE BEADS
K8004 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
TH101 NAD0006-103X THERMISTOR 10k Ω
X4701 QAX0246-001Z C RESONATOR 8.00MHz
 Symbol No. Part No. Part Name Description Local
IC501 PT6315 IC
IC511 GP1UM261XKVF IR DETECT UNIT
IC601 MM1623XF-X IC
IC651 CD4066BM-X IC
IC652 RC4558D-X IC
 IC901 STR-W6765N IC A,UB,UY
 IC901 STR-X6768N IC
US,UW,UX,
UJ,UG,UN
IC951 KIA431A-T IC
IC952 SN74LV04ANS-X IC
IC953 PQ1CG2032FZ IC
Q6501 KRC104S-X TRANSISTOR
Q6502 KRC104S-X TRANSISTOR
Q6601 KTC3875/YG/-X TRANSISTOR
Q6701 KTC3875/YG/-X TRANSISTOR
Q9001 2SJ632-X POWER MOS FET
Q9002 KTA1504/YG/-X TRANSISTOR
Q9003 KTC3875/YG/-X TRANSISTOR
Q9004 KRA102S-X DIGI TRANSISTOR
Q9011 2SJ609 POWER MOS FET
Q9013 KTC3875/YG/-X TRANSISTOR
Q9031 KRC102S-X DIGI TRANSISTOR
Q9032 KRC102S-X DIGI TRANSISTOR
Q9034 KRC102S-X DIGI TRANSISTOR
Q9036 KTC3265/Y/-X TRANSISTOR
Q9037 KTA1504/YG/-X TRANSISTOR
Q9038 KRC104S-X TRANSISTOR
Q9039 2SJ651 POWER MOS FET
Q9041 RTQ035P02-W MOS FET
D511 SLR-343VC/NPQ-T LED
 D901 D3SBA60 BRIDGE DIODE
 Symbol No. Part No. Part Name Description Local
