JVC TH-R1 User Manual

3-14
Front board
Block No. [0][2]
R6517 NRSA63J-104X MG RESISTOR 100k Ω 1/16W J
R6518 NRSA63J-223X MG RESISTOR 22k Ω 1/16W J
R6601 NRSA63J-104X MG RESISTOR 100k Ω 1/16W J
R6602 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R6603 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R6605 NRSA63J-103X MG RESISTOR 10k
Ω 1/16W J
R6606 NRSA63J-103X MG RESISTOR 10k
Ω 1/16W J
R6607 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R6608 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R6609 NRSA63J-473X MG RESISTOR 47k Ω 1/16W J
R6610 NRSA63J-104X MG RESISTOR 100k Ω 1/16W J
R6611 NRSA63J-333X MG RESISTOR 33k Ω 1/16W J
R6612 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R6613 NRSA63J-104X MG RESISTOR 100k Ω 1/16W J
R6614 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R6615 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R6616 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R6617 NRSA63J-104X MG RESISTOR 100k Ω 1/16W J
R6618 NRSA63J-223X MG RESISTOR 22k Ω 1/16W J
 L901 QQR1105-001 LINE FILTER
L951 QQL244K-R22Z COIL 0.22uH K
L952 QQL44BK-220Z COIL 22uH K
L955 QQL26AK-220Z COIL 22uH K
L957 QQL244K-100Z COIL 10uH K
L959 QQL244K-100Z COIL 10uH K
L4391 QQL25CK-221Z COIL 220uH K
 T901 QQS0097-001 SW TRANSF
CN401 QGF1036C1-15 CONNECTOR FFC/FPC (1-15)
CN402 QGF1036C1-25 CONNECTOR FFC/FPC (1-25)
CN404 QGD2504C1-05Z CONNECTOR (1-5)
CN405 QGD2504C1-05Z CONNECTOR (1-5)
CN406 QGD2504C1-04Z CONNECTOR (1-4)
CN407 QGD2504C1-05Z CONNECTOR (1-5)
CN408 QGF1036C1-05 CONNECTOR FFC/FPC (1-5)
CN410 QGF1205C1-11 CONNECTOR FFC/FPC (1-11)
CN411 QGF1036C1-29 CONNECTOR FFC/FPC (1-29)
CN412 QGF1036C1-07 CONNECTOR FFC/FPC (1-7)
CN420 QGD2504C1-04Z CONNECTOR (1-4)
CN451 QGF1036C1-13 CONNECTOR FFC/FPC (1-13)
CN452 QGF1205C1-05 CONNECTOR FFC/FPC (1-5)
CN460 QGF1205C1-05 CONNECTOR FFC/FPC (1-5)
CN480 QGF1205C1-05 CONNECTOR FFC/FPC (1-5)
 CP951 ICP-N10-T IC PROTECTOR 400mA
 CP953 ICP-N5-T IC PROTECTOR 250mA
EP401 QNZ0136-001Z EARTH PLATE
EP402 QNZ0136-001Z EARTH PLATE
EP403 QNZ0136-001Z EARTH PLATE
EP901 QNZ0136-001Z EARTH PLATE
EP902 QNZ0136-001Z EARTH PLATE
FC901 QNG0003-001Z FUSE CLIP
FC902 QNG0003-001Z FUSE CLIP
FW901 QUM219-06DGZ4-E PARA RIBON WIR
FW902 QUM21A-06DGZ4-E PARA RIBON WIR
HS901 LV40057-009A HEAT SINK
J4402 QNN0572-001 PIN JACK
J4403 QNZ0625-001 RGB CONNECTOR
 P901 QNC0091-001 AC INLET
X4071 QAX0868-001Z C RESONATOR
X4701 QAX0246-001Z C RESONATOR 8.00MHz
 Symbol No. Part No. Part Name Description Local
IC151 CD4066BM-X IC
IC152 CD4066BM-X IC
IC153 BD3814FV-X IC
IC154 CD4066BM-X IC
IC158 RC4558D-X IC
IC159 RC4558D-X IC
IC160 RC4558D-X IC
 Symbol No. Part No. Part Name Description Local
IC501 PT6315 IC
IC509 GP1FAV30RK0F OPT RECEIVER
IC511 GP1UM271XKVF IR DETECT UNIT
IC531 RC4558D-X IC
IC581 RC4558D-X IC
IC591 RC4558D-X IC
Q1131 IMX9-W TRANSISTOR
Q1133 IMX9-W TRANSISTOR
Q1135 IMX9-W TRANSISTOR
Q1137 2SC3661-X TRANSISTOR
Q1251 KRA104S-X DIGI TRANSISTOR
Q1252 KRA104S-X DIGI TRANSISTOR
D511 SLI-343URC-W-T LED
D551 SLR-343BCT/K/-T LED I/M
C505 NCB30JK-105X C CAPACITOR 1uF 6.3V K
C507 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C508 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C511 NCB21CK-105X C CAPACITOR 1uF 16V K
C1001 QETN1EM-107Z E CAPACITOR 100uF 25V M
C1002 QETN1EM-107Z E CAPACITOR 100uF 25V M
C1003 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C1101 NCB31HK-331X C CAPACITOR 330pF 50V K
C1102 NCB31HK-331X C CAPACITOR 330pF 50V K
C1103 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C1120 NCB31CK-333X C CAPACITOR 0.033uF 16V K
C1121 NCB31CK-333X C CAPACITOR 0.033uF 16V K
C1122 NCB31CK-333X C CAPACITOR 0.033uF 16V K
C1123 NCB31CK-333X C CAPACITOR 0.033uF 16V K
C1124 NCB31HK-472X C CAPACITOR 4700pF 50V K
C1125 NCB31HK-472X C CAPACITOR 4700pF 50V K
C1141 QETN1EM-107Z E CAPACITOR 100uF 25V M
C1142 QETN1EM-107Z E CAPACITOR 100uF 25V M
C1145 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C1176 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C1177 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C1178 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C1179 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C1180 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C1181 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C1183 QETN1HM-475Z E CAPACITOR 4.7uF 50V M
C1184 QETN1EM-476Z E CAPACITOR 47uF 25V M
C1191 NCB31HK-331X C CAPACITOR 330pF 50V K
C1192 NCB31HK-331X C CAPACITOR 330pF 50V K
C1193 NCB31HK-331X C CAPACITOR 330pF 50V K
C1194 NCB31HK-331X C CAPACITOR 330pF 50V K
C1195 NCB31HK-331X C CAPACITOR 330pF 50V K
C1196 NCB31HK-331X C CAPACITOR 330pF 50V K
C1201 QETN1EM-476Z E CAPACITOR 47uF 25V M
C1202 QETN1EM-476Z E CAPACITOR 47uF 25V M
C1203 QETN1EM-476Z E CAPACITOR 47uF 25V M
C1204 QETN1EM-476Z E CAPACITOR 47uF 25V M
C1205 QETN1HM-475Z E CAPACITOR 4.7uF 50V M
C1206 QETN1HM-475Z E CAPACITOR 4.7uF 50V M
C1207 QETN1HM-475Z E CAPACITOR 4.7uF 50V M
C1208 QETN1HM-475Z E CAPACITOR 4.7uF 50V M
C1209 QETN1HM-475Z E CAPACITOR 4.7uF 50V M
C1210 QETN1HM-475Z E CAPACITOR 4.7uF 50V M
C1211 QETN1HM-475Z E CAPACITOR 4.7uF 50V M
C1212 QETN1HM-475Z E CAPACITOR 4.7uF 50V M
C1213 QETN1HM-475Z E CAPACITOR 4.7uF 50V M
C1214 QETN1HM-475Z E CAPACITOR 4.7uF 50V M
C1215 QETN1HM-475Z E CAPACITOR 4.7uF 50V M
C1216 QETN1HM-475Z E CAPACITOR 4.7uF 50V M
C1217 QETN1HM-475Z E CAPACITOR 4.7uF 50V M
C1218 QETN1HM-475Z E CAPACITOR 4.7uF 50V M
C1221 NRSA63J-133X MG RESISTOR 13k Ω 1/16W J
C1222 NRSA63J-133X MG RESISTOR 13k Ω 1/16W J
C1227 NCB31CK-183X C CAPACITOR 0.018uF 16V K
C1228 NCB31CK-183X C CAPACITOR 0.018uF 16V K
C1230 QETN1HM-475Z E CAPACITOR 4.7uF 50V M
C1250 NCB31HK-102X C CAPACITOR 1000pF 50V K
C1251 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C1252 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C1253 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C1254 NCB31HK-103X C CAPACITOR 0.01uF 50V K
 Symbol No. Part No. Part Name Description Local
