3-19
DVD module board
Block No. [0][4]
R3106 NRSA63J-470X MG RESISTOR 47 Ω 1/16W J
R3107 NRSA63J-334X MG RESISTOR 330k Ω 1/16W J
R3108 NRSA63J-101X MG RESISTOR 100 Ω 1/16W J
R3109 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R3110 NRSA63J-104X MG RESISTOR 100k Ω 1/16W J
R3111 NRSA63J-471X MG RESISTOR 470
Ω 1/16W J
R3112 NRSA63J-103X MG RESISTOR 10k
Ω 1/16W J
R3113 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R3201 NRSA63J-153X MG RESISTOR 15k Ω 1/16W J
R3203 NRSA63J-222X MG RESISTOR 2.2k Ω 1/16W J
R3204 NRSA63J-183X MG RESISTOR 18k Ω 1/16W J
R3205 NRSA63J-474X MG RESISTOR 470k Ω 1/16W J
R3206 NRSA63J-470X MG RESISTOR 47 Ω 1/16W J
R3207 NRSA63J-334X MG RESISTOR 330k Ω 1/16W J
R3208 NRSA63J-101X MG RESISTOR 100 Ω 1/16W J
R3209 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R3210 NRSA63J-104X MG RESISTOR 100k Ω 1/16W J
R3211 NRSA63J-471X MG RESISTOR 470 Ω 1/16W J
R3212 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R3213 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R3301 NRSA63J-153X MG RESISTOR 15k
Ω 1/16W J
R3303 NRSA63J-222X MG RESISTOR 2.2k
Ω 1/16W J
R3304 NRSA63J-183X MG RESISTOR 18k Ω 1/16W J
R3305 NRSA63J-474X MG RESISTOR 470k Ω 1/16W J
R3306 NRSA63J-470X MG RESISTOR 47 Ω 1/16W J
R3307 NRSA63J-334X MG RESISTOR 330k Ω 1/16W J
R3308 NRSA63J-101X MG RESISTOR 100 Ω 1/16W J
R3309 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R3310 NRSA63J-104X MG RESISTOR 100k Ω 1/16W J
R3311 NRSA63J-471X MG RESISTOR 470 Ω 1/16W J
R3312 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R3313 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R3401 NRSA63J-153X MG RESISTOR 15k Ω 1/16W J
R3403 NRSA63J-222X MG RESISTOR 2.2k Ω 1/16W J
R3404 NRSA63J-183X MG RESISTOR 18k Ω 1/16W J
R3405 NRSA63J-474X MG RESISTOR 470k Ω 1/16W J
R3406 NRSA63J-470X MG RESISTOR 47 Ω 1/16W J
R3407 NRSA63J-334X MG RESISTOR 330k Ω 1/16W J
R3408 NRSA63J-101X MG RESISTOR 100 Ω 1/16W J
R3409 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R3410 NRSA63J-104X MG RESISTOR 100k Ω 1/16W J
R3411 NRSA63J-471X MG RESISTOR 470 Ω 1/16W J
R3412 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R3413 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R3501 NRSA63J-153X MG RESISTOR 15k Ω 1/16W J
R3503 NRSA63J-222X MG RESISTOR 2.2k Ω 1/16W J
R3504 NRSA63J-183X MG RESISTOR 18k Ω 1/16W J
R3505 NRSA63J-474X MG RESISTOR 470k Ω 1/16W J
R3506 NRSA63J-470X MG RESISTOR 47 Ω 1/16W J
R3507 NRSA63J-334X MG RESISTOR 330k
Ω 1/16W J
R3508 NRSA63J-101X MG RESISTOR 100 Ω 1/16W J
R3509 NRSA63J-102X MG RESISTOR 1k
Ω 1/16W J
R3510 NRSA63J-104X MG RESISTOR 100k
Ω 1/16W J
R3511 NRSA63J-471X MG RESISTOR 470 Ω 1/16W J
R3512 NRSA63J-103X MG RESISTOR 10k
Ω 1/16W J
R3513 NRSA63J-103X MG RESISTOR 10k
Ω 1/16W J
R3601 NRSA63J-153X MG RESISTOR 15k Ω 1/16W J
R3603 NRSA63J-222X MG RESISTOR 2.2k
Ω 1/16W J
R3604 NRSA63J-183X MG RESISTOR 18k Ω 1/16W J
R3605 NRSA63J-154X MG RESISTOR 150k
Ω 1/16W J
R3607 NRSA63J-104X MG RESISTOR 100k
Ω 1/16W J
R3608 NRSA63J-101X MG RESISTOR 100 Ω 1/16W J
R3610 NRSA63J-104X MG RESISTOR 100k
Ω 1/16W J
R3611 NRSA63J-471X MG RESISTOR 470
Ω 1/16W J
R3717 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R3719 QRE141J-102Y C RESISTOR 1k
Ω 1/4W J
 R3720 QRJ146J-100X UNF C RESISTOR 10 Ω 1/4W J
R3721 NRSA63J-221X MG RESISTOR 220
Ω 1/16W J
R3725 NRSA63J-472X MG RESISTOR 4.7k
Ω 1/16W J
R3726 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
 R3727 QRL01DJ-180X OMF RESISTOR 18 Ω 1W J
R3728 NRSA63J-101X MG RESISTOR 100
Ω 1/16W J
R3729 NRSA63J-473X MG RESISTOR 47k Ω 1/16W J
R3730 NRSA63J-470X MG RESISTOR 47
Ω 1/16W J
R3732 NRSA63J-153X MG RESISTOR 15k
Ω 1/16W J
R3741 NRSA63J-473X MG RESISTOR 47k Ω 1/16W J
R3742 NRSA63J-104X MG RESISTOR 100k
Ω 1/16W J
 Symbol No. Part No. Part Name Description Local
L2101 QQLZ005-R45 COIL 0.45uH
L2201 QQLZ005-R45 COIL 0.45uH
L2202 QQLZ005-R45 COIL 0.45uH
L2301 QQLZ005-R45 COIL 0.45uH
L2302 QQLZ005-R45 COIL 0.45uH
L2401 QQLZ005-R45 COIL 0.45uH
L2402 QQLZ005-R45 COIL 0.45uH
L2501 QQLZ005-R45 COIL 0.45uH
L2502 QQLZ005-R45 COIL 0.45uH
L2601 QQLZ005-R45 COIL 0.45uH
L2602 QQLZ005-R45 COIL 0.45uH
 CN101 QGA7901C1-02 CONNECTOR W-B (1-2)
 CN102 QGA7901C1-02 CONNECTOR W-B (1-2)
CN151 QGA3901C1-05 CONNECTOR W-B (1-5)
CN271 QGB2510J1-14 CONNECTOR B-B (1-14)
CN272 QGB2510J1-09 CONNECTOR B-B (1-9)
CN273 QGB2510J1-14 CONNECTOR B-B (1-14)
CN274 QGA3901C1-02 CONNECTOR W-B (1-2)
CN371 QGA2501C1-02 CONNECTOR W-B (1-2)
CN372 QGB2510K2-09 CONNECTOR B-B (1-9)
CN373 QGA2501C1-02 CONNECTOR W-B (1-2)
CN501 QGB2510K2-14 CONNECTOR B-B (1-14)
CN502 QGB2510K2-14 CONNECTOR B-B (1-14)
EP201 QNZ0136-001Z EARTH PLATE
EP501 QNZ0136-001Z EARTH PLATE
FC101 QNG0019-001Z FUSE CLIP
FC102 QNG0019-001Z FUSE CLIP
FC155 QNG0019-001Z FUSE CLIP
FC156 QNG0019-001Z FUSE CLIP
FC157 QNG0019-001Z FUSE CLIP
FC158 QNG0019-001Z FUSE CLIP
FW501 QUM213-28Z4Z4-E RIBBON WIRE
HS151 QZW0138-001 HEAT SINK
J2701 QND0118-001 DIN CONNECTOR
J2702 QNB0195-001 SPEAKER TERMINA
 RY101 QSK0142-001 RELAY
RY271 QSK0127-001 RELAY
RY272 QSK0127-001 RELAY
RY273 QSK0127-001 RELAY
TH271 NAD0025-103X N THERMISTOR 10k Ω
WC201 QZW0112-001 WIRE CLAMP
X601 QAX0246-001Z C RESONATOR 8.00MHz
 Symbol No. Part No. Part Name Description Local
IC201 LA6502-X IC
IC301 MN2DS0009AA IC
IC302 MM1701CH-X IC
IC305 MM1563BF-X IC 3.1V Regulator
IC453 S-80827CNNB-G-W IC
IC505 K4S641632H-UC75 IC
IC505 or HY57V641620ETP7 IC(DIGITAL)
IC509 SG32M90TFIR3 IC(MICRO C ROM)
IC510 BR24L16FV-W-X IC
IC701 AK4384VT-X IC
IC701 or AK4384ET-X IC
IC702 AK4384VT-X IC
IC702 or AK4384ET-X IC
IC703 AK4384VT-X IC
IC703 or AK4384ET-X IC
IC704 AK5357VT-X IC
IC704 or AK5357ET-X IC
IC705 MM1615AN-X IC
Q101 KTA1001/Y/-X TRANSISTOR
Q101 or 2SB1424/R/-W TRANSISTOR
Q102 2SC4617/R/-X TRANSISTOR
Q103 KTA1001/Y/-X TRANSISTOR
Q103 or 2SB1424/R/-W TRANSISTOR
Q104 2SC4617/R/-X TRANSISTOR
 Symbol No. Part No. Part Name Description Local
