7 Center unit (XV-THS3)
Audio section
Front/Center/Surround: 52 W per channel, RMS at 6 C at 1
kHz, with 10 % total harmonic
distortion.
Subwoofer: 52 W, RMS at 6 C at 100 Hz, with
10 % total harmonic distortion.
Digital input*
1
:
OPTICAL DIGITAL IN:
–21 dBm to –15 dBm (660 nm E 30 nm)
*
1
Corresponding to Linear PCM, Dolby Digital, and DTS Digital
Surround (with sampling frequency — 32 kHz, 44.1 kHz, 48 kHz)
Video section
Video System: NTSC/PAL
Horizontal Resolution: 500 lines
Signal-to-Noise Ratio: 64 dB
Video output level
Composite: 1.0 V(p-p)/75 C
S-video-Y: 1.0 V(p-p)/75 C
S-video-C: 0.286 V (0.3 V*
2
)(p-p)/75 C
Component-Y: 1.0 V(p-p)/75 C
Component-P
B/PR: 0.7 V(p-p)/75 C
*2
For PAL system
Tuner section
Tuning Range
FM: 87.50 MHz to 108.00 MHz
AM: 531 kHz to 1602 kHz
(at 9 kHz cannel spacing)
530 kHz to 1600 kHz
(at 10 kHz cannel spacing)
General
Power Requirements: AC 110 V/ AC 127 V/ AC 220 V/
AC 230-240V , 50/60 Hz
Power Consumption: 75 W (at operation)
1.0 W (in standby mode)
Dimensions (W M H M D): 360 mm M 65 mm M 370 mm
Mass: 5.3 kg
7 Front speakers (SP-THS3F)
Type: 1-Way Bass-Reflex Type
(Magnetically-shielded Type)
Speaker: 8.0 cm cone M 1
Power Handling Capacity: 52 W
Impedance: 6 C
Frequency Range: 85 Hz to 20 000 Hz
Sound Pressure Level: 82 dB/W
·m
Dimensions (W M H M D): 105 mm M 118 mm M 98 mm
Mass: 0.60 kg each
7 Center speaker (SP-THS3F)
Type: 1-Way Bass-Reflex Type
(Magnetically-shielded Type)
Speaker: 8.0 cm cone M 1
Power Handling Capacity: 52 W
Impedance: 6 C
Frequency Range: 85 Hz to 20 000 Hz
Sound Pressure Level: 82 dB/W
·m
Dimensions (W M H M D): 105 mm M 118 mm M 98 mm
Mass: 0.65 kg
7 Surround Speakers (SP-THS3F)
Type: 1-Way Bass-Reflex Type
(Magnetically-shielded Type)
Speaker: 8.0 cm cone M 1
Power Handling Capacity: 52 W
Impedance: 6 C
Frequency Range: 85 Hz to 20 000 Hz
Sound Pressure Level: 80 dB/W
·m
Dimensions (W M H M D): 105 mm M 118 mm M 98 mm
Mass: 0.55 kg each
7 Subwoofer (SP-WS3)
Type: 1-Way Bass-Reflex Type
(Magnetically-shielded Type)
Speaker: 16 cm cone M 1
Power Handling Capacity: 52 W
Impedance: 6 C
Frequency Range: 40 Hz to 1 800 Hz
Sound Pressure Level: 85 dB/W
·m
Dimensions (W M H M D): 139 mm M 350 mm M 408 mm
Mass: 4.0 kg
Designs & specifications are subject to change without notice.
