JVC TM-A170G Operating Instructions

1-10
TM-A170G
ENGLISH
395 (15-5/8")
418 (16-1/2")
407 (16-1/8")
68
(2-3/4")
286 (11-3/8")
3 (1/8")
336.3 (13-1/14")*
288 (11-3/8")
ø20
(ø7/8")
256 (10-3/8")*
334 (13-1/4")
175 (7")
1.5
(1/16")
POWER
CHROMA MENU
INPUT SELECT
PHASE
TM-A170
BRIGHT
CONTRAST VOLUME/SELECT
AB
3 (1/8")
 Dimensions
< Front View >
< Side View >
* Asterisks ( * ) are used to indicate front panel
dimensions.
Unit : mm (inch)
Pin No. Signal
1 GND (Y)
2 GND (C)
3Y
4C
 Y/C (Mini DIN 4 pin) terminal
specification
IN
Y/C
OUT
2
1
2
1
4
3
4
3
17
