CAPACITOR
TRANSFORMER
C6512 QETN1HM-106Z
E CAP. lOµF 50V
T6241 QQR1018-001
I. F. TRANSFORMER
C6513 QETN1CM-107Z
E CAP. lOOµF 16V
C6514 NCF21HZ-104X C CAP. 0. lµF
50V
C6515-22 NCB21EK-104X C CAP. 0. lµF 25V
COIL
C6523 QETN1CM-107Z
E CAP. lOOµF
16V
C6524 NCF21HZ-104X C CAP.
0. lµF 50V
L6101 QQL244K-220Z
PEAKING COIL
22µH
C6525 QETN1CM-107Z E CAP.
lOOµF 16V
C6526 NCF21HZ-104X C CAP.
0. lµF 50V
L6151
QQL244K-5R6Z PEAKING COIL
5. 6µH
L6152
QQL244K-270Z PEAKING COIL
27µH
C6527 QETN1HM-225Z
E CAP. 2. 2µF 50V
L6241 QQL244K-8R2Z
PEAKING COIL 8. 2µH
C6528-30 NCB21EK-104X C CAP. 0. lµF 25V
L6601-02 QQL244K-820Z PEAKING COIL
82µH
C6531 NCB21CK-474X
C CAP. 0 .47µF 16V
L6701
QQL244K-4R7Z PEAKING COIL
4. 7µH
C6532 QETN1HM-225Z
E CAP. 2. 2µF
50V
L6702 QQL244K-8R2Z
PEAKING COIL
8. 2µH
C6533
NCB21EK-104X C CAP. 0. lµF 25V
C6534
QETN1HM-475Z E CAP.
4. 7µF 50V
C6535
QETN1CM-107Z E CAP.
lOOµF 16V
DIODE
C6536
NCF21HZ-104X C CAP.
0. lµF 50V
D6001-06
MAlll-X
SI. DIODE
C6537-38 NDC21HJ-120X C CAP. 12pF
50V
D6007
MA3091/M/-X
ZENER DIODE
C6539
NCF21HZ-104X C CAP.
O. lµF 50V
D6101
MAlll-X SI. DIODE
C6540 QETN1HM-105Z E CAP.
lµF 50V
D6401-02
MA111-X
SI. DIODE
C6541-42
QETN1EM-476Z
E CAP. 47µF 25V
D6501-10
MAlll-X SI. DIODE
C6601 NDC21HJ -390X C CAP.
39pF 50V
D6511
MA3068/M/ -X ZENER DIODE
C6602 NDC21HJ-8ROX C CAP.
8. OpF 50V
D6514-18
MAlll-X
SI. DIODE
C6603
NDC21HJ-181X C CAP.
180pF 50V
D6702-04
MAlll-X
SI. DIODE
C6604 NDC21HJ -390X C CAP.
39pF 50V
D6705-07 MA3051/M/-X ZENER DIODE
C6605
NDC21HJ-8ROX C CAP.
8. OpF 50V
D6708
MA111-X
SI. DIODE
C6606
NDC21HJ-181X C CAP.
180pF 50V
D6709
MA3120/M/-X
ZENER DIODE
C6607 -08 NCB21EK-104X C CAP.
0. lµF 25V
D6710-ll
MAlll-X
SI. DIODE
C6609 QETN1CM-107Z
E CAP. lOOµF 16V
D6801-04
MA111-X
SI.DIODE
C6610
NCF21HZ -104X
C CAP.
0. lµF 50V
D6861-64 MAlll-X SI. DIODE
C6611-12 NCB21EK-104X
C CAP. 0. lµF 25V
C6613 QETN1HM-106Z
E CAP. lOµF 50V
C6614-15 NCB21EK-104X C CAP. 0. lµF 25V
TRANSISTOR
C6616
QENC1HM-474Z BP E CAP. 0. 47µF
50V
Q6001-03
2SC2412K/QR/-X
SI. TRANSISTOR
C6617 QETN1CM-107Z E CAP. lOOµF
16V
Q6101-05
2SC2412K/QR/-X
SI. TRANSISTOR
C6618
NCF21HZ-104X C CAP. 0. lµF
50V
Q6106
DTC124EKA-X
DIG!. TRANSISTOR
C6619 QENC1HM-474Z BP E CAP.
0. 47µF 50V Q6109
DTC124EKA-X
DIG!. TRANSISTOR
C6620-22
QETN1HM-105Z
E CAP. lµF 50V
Q6110-11
2SC2412K/QR/-X SI. TRANSISTOR
C6623-27 NCB21EK-104X C CAP.
0. lµF 25V
Q6112
2SA1037AK/QR/-X SI. TRANSISTOR
C6636-37
NDC21HJ-101X
C CAP. lOOpF 50V
Q6113-15
2SC2412K/QR/-X SI. TRANSISTOR
C6701 QENC1EM-106Z
BP E CAP. lOµF 25V
Q6151-53
2SC2412K/QR/-X SI. TRANSISTOR
C6702 NDC21HJ-560X
C CAP. 56pF 50V
Q6154
2SA1037AK/QR/-X SI. TRANSISTOR
C6703 NDC21HJ-680X
C CAP. 68pF 50V
Q6155
2SC2412K/QR/-X SI. TRANSISTOR
C6704 QETN1CM-107Z
E CAP. lOOµF 16V
Q6156
DTC124EKA-X DIG!. TRANSISTOR
C6705
NCF21HZ-104X C CAP. 0. lµF 50V
Q6158-60 2SC2412K/QR/-X
SI. TRANSISTOR
C6706 QETN1CM-227Z
E CAP. 220µF 16V
Q6201-04 2SC2412K/QR/-X
SI. TRANSISTOR
Q6206-08 2SC2412K/QR/-X
SI. TRANSISTOR
C6707-08 NCF21HZ-104X C CAP. 0. lµF 50V
Q6210 2SC2412K/QR/-X
SI. TRANSISTOR
C6709 QETN1EM-227Z
E CAP. 220µF 25V
Q6211
2SA1037AK/QR/-X
SI. TRANSISTOR
C6710 QETN1HM-225Z
E CAP. 2. 2µF 50V
C6801
NDC21HJ-681X
Q6241-43 2SC2412K/QR/-X
SI. TRANSISTOR
C CAP. 680pF 50V
Q6244
DTC124EKA-X DIG!. TRANSISTOR
C6802
NDC21HJ-102X C CAP. lOOOpF 50V
Q6401
2SC2412K/QR/-X
SI. TRANSISTOR
C6803
NDC21HJ-681X C CAP. 680pF 50V
Q6402
2SA965/0Y /-T
SI. TRANSISTOR
C6804
NDC21HJ-102X C CAP. lOOOpF 50V
Q6512-15 2SC2412K/QR/-X
SI. TRANSISTOR
C6805
NCF21HZ-104X C CAP. 0. lµF
50V
Q6516
DTC124EKA-X DIG!. TRANSISTOR
C6806 QETN1CM-107Z
E CAP. lOOµF 16V
Q6518-20
2SA1037AK/QR/-X
SI. TRANSISTOR
C6807 NCF21HZ-104X C CAP. 0. lµF
50V
Q6522
2SA1037AK/QR/-X
SI. TRANSISTOR
C6808 QETN1CM-107Z
E CAP. lOOµF 16V
Q6523
2SC2412K/QR/-X
SI. TRANSISTOR
C6809 NDC21HJ-331X C CAP.
330pF 50V
Q6524
2SA1037AK/QR/-X
SI. TRANSISTOR
C6810 NDC21HJ-102X C CAP.
lOOOpF 50V
Q6601-08
2SC2412K/QR/-X
SI. TRANSISTOR
C6861-62 NDC21HJ-101X C CAP.
lOOpF 50V
Q6609
DTC124EKA-X DIG!. TRANSISTOR
C6901 NCF21HZ-104X C CAP. 0. lµF 50V
Q6623-24
2SA1037AK/QR/-X
SI. TRANSISTOR
C6902-03 QETN1CM-107Z E CAP. lOOµF
16V
Q6701-02
DTA124EKA-X
DIG!. TRANSISTOR
C6904-05 NCF21HZ-104X C CAP.
0. lµF 50V
Q6705-06
DTA124EKA-X DIG!. TRANSISTOR
C6906 QETN1CM-107Z E CAP.
lOOµF 16V
Q6707
DTC124EKA-X
DIG!. TRANSISTOR
C6909
NCF21HZ -104X
C CAP.
0. lµF 50V
Q6708
2SC2412K/QR/-X
SI. TRANSISTOR
C6910-11
QETN1CM-107Z
E CAP. lOOµF 16V
Q6710
DTC124EKA-X
DIG!. TRANSISTOR
Q6712
2SC2412K/QR/-X
SI. TRANSISTOR
C6912
NCF21HZ-104X C CAP. 0. lµF 50V
Q6801-03
2SC2412K/QR/-X
SI. TRANSISTOR
