TM-H150CG
Color video monitor
PAL, NTSC (3.58)
39 cm (15") measured diagonally,
90° deflection, in-line gun,
trio-dot type
(phosphor dot-trio pitch 0.27 mm)
Width: 285.5 mm (11 3/16")
Height: 214 mm (8 3/8")
Diagonal: 356 mm (14")
H: 15.734 kHz (NTSC), 15.625 kHz (PAL)
V: 59.94 Hz (NTSC), 50 Hz (PAL)
750 TV lines or more
(Y/C input mode)
Composite video: 1 line, BNC connector x 2,
1 V(p-p), 75 Ω, negative sync
(bridge connection possible, auto termination)
Composite video: 1 line, BNC connector x 2,
1 V(p-p), 75 Ω, negative sync
(bridge connection possible, auto termination)
Y/C-separated: 1 line, mini-DIN 4-pin connector x 2
Y: 1 V (p-p), 75 Ω
C (BURST): 0.286 V (p-p), 75 Ω (NTSC) 0.3 V (p-p), 75 Ω (PAL)
(bridge connection possible, auto termination)
1 line (monaural), RCA pin x 2, 0.5 V(rms), high-impedance
(bridge connection possible)
1 line (monaural), RCA pin x 2, 0.5 V(rms), high-impedance
(bridge connection possible)
Point-of-contact connection, 1 line D-sub connector (15-pin, 3-line)
1 W
8 cm round x 1, impedance of 8 Ω
Operation temperature: 5°C – 40°C (41°F – 104°F)
Operation humidity: 20 % – 80 % (non-condensing)
120 V/220 – 240 V AC, 50 Hz/ 60 Hz
1.2 A (120 V AC)/0.8 A (220 – 240 V AC)
Width: 360 mm (14 1/4")
Height: 310 mm (12 1/4")
Depth: 418 mm (16 1/2")
16 kg (35.2 lbs)
(not including input card)
AC power cord
Specifications
• Illustrations used in this manual are for explanatory purposes only. The appearance of the actual product may differ slightly.
• Dimensions and weight are approximate.
• E. & O. E. Design and specifications subject to change without notice.
MODEL
Type
Color system
Picture tube
Effective screen size
Scanning frequency
Horizontal resolution
Input terminals VIDEO A
VIDEO B
AUDIO A
AUDIO B
REMOTE
Audio power output
Built-in speaker
Environmental conditions
Power requirements
Power consumption
Dimensions
Weight
Accessory
