JVC UX-G500V

45
USB section
Playable files: MP3/WMA/WAV/JPEG/MPEG-1/
MPEG-2/DivX format
USB specification: Compatible with USB 2.0 Full Speed
Compatible device: Mass storage class
Compatible system: FAT16, FAT32
Bus power supply: DC 5 V
500 mA
General
Power requirements: AC 110 V – 240 V , 50/60 Hz
For Australia: AC 240 V
, 50 Hz
For Hong Kong region
and Thailand: AC 220 V
, 50 Hz
Power consumption: 35 W (at operation)
8 W (at standby)
1 W or less (at ECO mode)
Dimensions (approx.): 175 mm × 251 mm × 247 mm
(W/H/D)
Mass (approx.): 2.6 kg
Speakers—SP-UXG500V
Speaker units: Tweeter: 1.5 cm dome x 1
Woofer: 10 cm cone x 1
Impedance: 4 Ω
Dimensions (approx.): 160 mm × 250 mm × 169 mm
(W/H/D)
Mass (approx.): 1.8 kg each
Supplied Accessories
See page 4.
Design and specifications are subject to change without
notice.
Specifications
Amplifier section—CA-UXG500V
Output power: 60 W (30 W + 30 W) at 4 Ω (10% THD)
Audio input: AUDIO IN: Stereo min. (∅ 3.5 mm)
500 mV/50 kΩ (at “IN_LVL1”)
250 mV/50 kΩ (at “IN_LVL2”)
125 mV/50 kΩ (at “IN_LVL3”)
Audio output: SUBWOOFER OUT: 500 mV/10 kΩ
Digital output: OPTICAL DIGITAL OUT:
–21 dBm to –15 dBm (660 nm ±30 nm)
Digital input: USB MEMORY
Video out:
Color system: NTSC/PAL (interlaced/progressive)
Composite video: 1 V(p-p)/75 Ω
S-VIDEO: Y (luminance) 1 V(p-p)/75 Ω
C (chrominance, burst)
PAL 0.3 V(p-p)/75 Ω
NTSC 0.286 V(p-p)/75 Ω
VIDEO OUT (COMPONENT): (Y) 1 V(p-p)/75 Ω
(PB/PR) 0.7 V(p-p)/75 Ω
Speaker impedance: 4 Ω – 16 Ω
Tuner section
FM tuning range: 87.50 MHz – 108.00 MHz
AM (MW) tuning range:
For Saudi Arabia:
531 kHz – 1 602 kHz (at 9 kHz intervals)
530 kHz – 1 600 kHz (at 10 kHz intervals)
For other countries:
531 kHz – 1 710 kHz (at 9 kHz intervals)
530 kHz – 1 710 kHz (at 10 kHz intervals)
Disc player section
Region codes: • Middle East: 2
• South East Asia, Hong Kong region: 3
• Central and South America, Australia: 4
Playable disc: • DVD Video/CD/VCD/SVCD
• CD-R/CD-RW (CD/SVCD/VCD/MP3/
WMA/WAV/JPEG/MPEG-1/MPEG-2/
DivX format)
• DVD-R/-RW (DVD-VR/DVD Video/
MP3/WMA/WAV/JPEG/MPEG-1/
MPEG-2/DivX format)
• +R/+RW (DVD Video/MP3/WMA/
WAV/JPEG/MPEG-1/MPEG-2/DivX
format)
Dynamic range: 80 dB
Horizontal resolution: 500 lines
Wow and flutter: Immeasurable
