1-22 (No.MB330)
4.3 Location of adjusting parts
CASSETTE MOTOR
Tape Speed Adj.
+
-
Cassette mechanism
Main board assembly
T103
T105
T101
T102
VR101
L102
T104
T106
TC102
L101
TC101
L203
