JVC UX-HB4

3-11
CD board
Block No. [0][4]
R575 OW07-75222-06 C RESISTOR 2.2K 1/16W
R576 OW07-75222-06 C RESISTOR 2.2K 1/16W
R577 OW07-75222-06 C RESISTOR 2.2K 1/16W
R578 OW07-75222-06 C RESISTOR 2.2K 1/16W
R579 OW07-75102-06 C RESISTOR 1K 1/16W
R580 OW07-75470-06 C RESISTOR 47 1/16W
R581 OW07-75471-06 C RESISTOR 470 1/16W
R582 OW07-75102-06 C RESISTOR 1K 1/16W
R583 OW07-75102-06 C RESISTOR 1K 1/16W
R584 OW07-75102-06 C RESISTOR 1K 1/16W
R585 OW07-75102-06 C RESISTOR 1K 1/16W
R586 OW07-75223-06 C RESISTOR 22K 1/16W
R587 OW07-75223-06 C RESISTOR 22K 1/16W
R588 OW07-75223-06 C RESISTOR 22K 1/16W
R589 OW07-75223-06 C RESISTOR 22K 1/16W
R590 OW07-75223-06 C RESISTOR 22K 1/16W
R591 OW07-75102-06 C RESISTOR 1K 1/16W
R592 OW07-75103-06 C RESISTOR 10K 1/16W
R593 OW07-75223-06 C RESISTOR 22K 1/16W
R594 OW07-75223-06 C RESISTOR 22K 1/16W
R595 OW07-75223-06 C RESISTOR 22K 1/16W
R596 OW07-75223-06 C RESISTOR 22K 1/16W
R598 OW07-75221-06 C RESISTOR 220 1/16W
R599 OW07-75221-06 C RESISTOR 220 1/16W
L501 OW09-70101-82T COIL 10uH
L502 OW09-70102-82T COIL 100uH
L503 OW09-70102-82T COIL 100uH
CN501 OW20-41082-48 CONECTOR WIRE 8P
CN503 OW20-41092-81 CONECTOR WIRE 9P
CN507 OW20-41092-71 CONECTOR WIRE 9P
FB01 OW08-04344-73 FERRITE BEAD 700 100MHz
FB02 OW08-04344-73 FERRITE BEAD 700 100MHz
FB03 OW08-04344-73 FERRITE BEAD 700 100MHz
FB04 OW08-04344-73 FERRITE BEAD 700 100MHz
FB05 OW08-04344-73 FERRITE BEAD 700 100MHz
FB06 OW08-04344-73 FERRITE BEAD 700 100MHz
FB08 OW08-04344-73 FERRITE BEAD 700 100MHz
FB09 OW08-04344-73 FERRITE BEAD 700 100MHz
FB10 OW08-04344-73 FERRITE BEAD 700 100MHz
FB11 OW07-75000-06F C RESISTOR 0 1/16W
FB12 OW08-04344-73 FERRITE BEAD 700 100MHz
FB13 OW08-04344-73 FERRITE BEAD 700 100MHz
FB14 OW08-04344-73 FERRITE BEAD 700 100MHz
FB15 OW08-04344-73 FERRITE BEAD 700 100MHz
FB16 OW08-04344-73 FERRITE BEAD 700 100MHz
FB17 OW08-04344-73 FERRITE BEAD 700 100MHz
FB18 OW05-73102-00 C CAPACITOR 1000pF 50V
FB19 OW08-04344-73 FERRITE BEAD 700 100MHz
FB20 OW08-04344-73 FERRITE BEAD 700 100MHz
FB21 OW08-04344-73 FERRITE BEAD 700 100MHz
FB22 OW08-04344-73 FERRITE BEAD 700 100MHz
FB23 OW08-04344-73 FERRITE BEAD 700 100MHz
FB30 OW07-75222-06 C RESISTOR 2.2K 1/16W
FB31 OW07-75222-06 C RESISTOR 2.2K 1/16W
FB32 OW07-75222-06 C RESISTOR 2.2K 1/16W
FB33 OW07-75222-06 C RESISTOR 2.2K 1/16W
J501 OW07-75001-05F C RESISTOR 0 1/8W
J502 OW07-75001-05F C RESISTOR 0 1/8W
J503 OW07-75001-05F C RESISTOR 0 1/8W
J504 OW07-75001-05F C RESISTOR 0 1/8W
J505 OW07-75001-05F C RESISTOR 0 1/8W
J506 OW07-75001-05F C RESISTOR 0 1/8W
J507 OW07-75001-05F C RESISTOR 0 1/8W
J508 OW07-75001-05F C RESISTOR 0 1/8W
J509 OW07-75001-05F C RESISTOR 0 1/8W
J510 OW07-75001-05F C RESISTOR 0 1/8W
J511 OW07-75001-05F C RESISTOR 0 1/8W
J512 OW07-75001-05F C RESISTOR 0 1/8W
J513 OW07-75001-05F C RESISTOR 0 1/8W
J514 OW07-75001-05F C RESISTOR 0 1/8W
J515 OW07-75001-05F C RESISTOR 0 1/8W
J516 OW07-75001-05F C RESISTOR 0 1/8W
J517 OW07-75001-05F C RESISTOR 0 1/8W
J518 OW07-75001-05F C RESISTOR 0 1/8W
J519 OW07-75001-05F C RESISTOR 0 1/8W
J520 OW07-75001-05F C RESISTOR 0 1/8W
 Symbol No. Part No. Part Name Description Local
J521 OW07-75001-05F C RESISTOR 0 1/8W
J522 OW07-75001-05F C RESISTOR 0 1/8W
J523 OW07-75001-05F C RESISTOR 0 1/8W
J524 OW07-75000-06F C RESISTOR 0 1/16W
J525 OW07-75000-06F C RESISTOR 0 1/16W
J526 OW07-75000-06F C RESISTOR 0 1/16W
J527 OW07-75000-06F C RESISTOR 0 1/16W
J528 OW07-75000-06F C RESISTOR 0 1/16W
J529 OW07-75102-06 C RESISTOR 1K 1/16W
J531 OW07-75001-05F C RESISTOR 0 1/8W
J532 OW07-75001-05F C RESISTOR 0 1/8W
J533 OW07-75001-05F C RESISTOR 0 1/8W
J534 OW07-75001-05F C RESISTOR 0 1/8W
J535 OW07-75001-05F C RESISTOR 0 1/8W
J538 OW07-75103-06 C RESISTOR 10K 1/16W
J540 OW07-74100-00T C RESISTOR 10 1/4W
J545 OW07-75000-06F C RESISTOR 0 1/16W
J558 OW07-75001-05F C RESISTOR 0 1/8W
J564 OW07-75001-05F C RESISTOR 0 1/8W
J565 OW07-75001-05F C RESISTOR 0 1/8W
J577 OW07-75000-06F C RESISTOR 0 1/16W
J580 OW07-75001-05F C RESISTOR 0 1/8W
RV501 OW18-92040-86 ENCODER VOL FIB-HA1-24
SW501 OW16-10101-80 TACT SWITCH Evqjae 05R
SW502 OW16-10101-80 TACT SWITCH Evqjae 05R
SW503 OW16-10101-80 TACT SWITCH Evqjae 05R
SW504 OW16-10101-80 TACT SWITCH Evqjae 05R
SW505 OW16-10101-80 TACT SWITCH Evqjae 05R
SW506 OW16-10101-80 TACT SWITCH Evqjae 05R
SW507 OW16-10101-80 TACT SWITCH Evqjae 05R
SW508 OW16-10101-80 TACT SWITCH Evqjae 05R
SW509 OW16-10101-80 TACT SWITCH Evqjae 05R
SW510 OW16-10101-80 TACT SWITCH Evqjae 05R
X501 OW04-12072-60 CRYSTAL 12.072MHz
X502 OW04-04332-80 CRYSTAL 4.332MHz 30pF
XXXXX OW07-74331-00T C RESISTOR 330 1/4W For ESD
XXXXX OW35-30005-80 SOLDERING LUG For ESD
XXXXX OW08-04344-50 FERRITE CORE For CN502
XXXXX OW11-00004-22 DISPLAY&MCU PCB 94VO 1.6mm
 Symbol No. Part No. Part Name Description Local
IC601 TC4052BF IC OW03-04052-00
IC602 ES3890F IC OW03-03890-00
IC603 W27C020-70 IC OW03-27207-00
IC605 HY511864 IC OW03-51181-64
IC606 WM8725 IC OW03-08725-00
IC608 S5L9290 IC OW03-09290-00
IC609 S1L9226 IC OW03-09226-00
IC610 IP4001 IC OW03-04001-11
 IC611 AME1117CCBT IC
OW03-01117-05
3.3V
Q602 KTD2058Y TRANSISTOR OW01-02058-80
Q604 8550 TRANSISTOR OW01-08550-86
 Q606 2SC1383R TRANSISTOR OW01-01383-80
C605 OW06-71106-00 E CAPACITOR 10uF 16V
C606 OW05-73104-00 C CAPACITOR 0.1uF 50V
C607 OW05-73122-00 C CAPACITOR 1200p 50V
C608 OW05-73104-00 C CAPACITOR 0.1uF 50V
C610 OW05-73270-05 C CAPACITOR 27pF 50V
C611 OW05-73270-05 C CAPACITOR 27pF 50V
C612 OW06-71107-20 E CAPACITOR 100uF 16V
C614 OW06-71107-20 E CAPACITOR 100uF 16V
C615 OW05-73104-00 C CAPACITOR 0.1uF 50V
C616 OW06-71107-20 E CAPACITOR 100uF 16V
C617 OW05-73104-00 C CAPACITOR 0.1uF 50V
C618 OW05-73104-00 C CAPACITOR 0.1uF 50V
C620 OW06-71107-20 E CAPACITOR 100uF 16V
C621 OW05-73104-00 C CAPACITOR 0.1uF 50V
 Symbol No. Part No. Part Name Description Local
