3-1
PARTS LIST
* All printed circuit boards and its assemblies are not available as service parts.
- Contents -
Exploded view of general assembly and parts list (Block No.M1)
DVD mechanism assembly and parts list (Block No.MJ)
DVD loading base assembly and parts list (Block No.MN)
Cassette mechanism assembly and parts list (Block No.MP)
Electrical parts list (Block No.01~05)
Packing materials and accessories parts list (Block No.M3)
[ UX-P550 ]
3- 2
3- 6
3- 8
3-10
3-12
3-22
Area suffix
US ---------------------- Singapore
UB --------------------- Hong Kong
UW ---------- Brazil,Mexico,Peru
UX ------------------- Saudi Arabia
UJ --------------------- U.S.Military
UN ----------------------------Asean
