3-15
Video board
Block No. [0][2]
Power board
Block No. [0][3]
K7375 NRSA02J-0R0X MG RESISTOR 0
Ω
1/10W J
PP12 QZW0038-001 WIRE CLAMP
S700 QSW0454-001 SW
X7001 QAX0718-001Z CRYSTAL 8.000000MHz
Symbol No.
Part No. Part Name Description Local
IC300 KIA7805API IC
IC301 MM1623XF-X IC
IC601 HA17558AF-X IC
IC602 BU9253FS-X IC
Q3005 KRC111S-X TRANSISTOR
Q6001 2SC2412K/R/-X TRANSISTOR
Q6002 2SC2412K/R/-X TRANSISTOR
Q6003 DTC114TKA-X TRANSISTOR
Q6004 2SA1037K/R/-X TRANSISTOR
Q6005 DTC144EKA-X DIGI TRANSISTOR
D6001 1SS119-041-T2 DIODE
D6002 1SS119-041-T2 DIODE
D6003 MTZJ5.1B-T2 Z DIODE
C3001 QFLC1HJ-103Z M CAPACITOR 0.01uF 50V J
C3002 QETN1CM-107Z E CAPACITOR 100uF 16V M
C3003 QFLC1HJ-103Z M CAPACITOR 0.01uF 50V J
C3004 QETN1CM-107Z E CAPACITOR 100uF 16V M
C3005 QCBB1HK-104Y C CAPACITOR 0.1uF 50V K
C3006 QETN1AM-477Z E CAPACITOR 470uF 10V M
C3007 QETN1CM-226Z E CAPACITOR 22uF 16V M
C3010 QCFB1HZ-105Y C CAPACITOR 1uF 50V Z
C3011 NCB30JK-105X C CAPACITOR 1uF 6.3V K
C3012 QCFB1HZ-105Y C CAPACITOR 1uF 50V Z
C3013 NCB30JK-105X C CAPACITOR 1uF 6.3V K
C3014 QETN0JM-477Z E CAPACITOR 470uF 6.3V M
C3015 QETN0JM-477Z E CAPACITOR 470uF 6.3V M
C3016 QETN0JM-477Z E CAPACITOR 470uF 6.3V M
C3017 NCS31HJ-181X C CAPACITOR 180pF 50V J
C3018 NCS31HJ-181X C CAPACITOR 180pF 50V J
C3019 NCS31HJ-181X C CAPACITOR 180pF 50V J
C3020 QETN0JM-477Z E CAPACITOR 470uF 6.3V M
C3021 QETN0JM-477Z E CAPACITOR 470uF 6.3V M
C3022 NCS31HJ-181X C CAPACITOR 180pF 50V J
C3023 NCS31HJ-181X C CAPACITOR 180pF 50V J
C3024 QETN0JM-477Z E CAPACITOR 470uF 6.3V M
C3025 NCS31HJ-181X C CAPACITOR 180pF 50V J
C3031 QCBB1HK-103Y C CAPACITOR 0.01uF 50V K
C6001 QETN1HM-474Z E CAPACITOR 0.47uF 50V M
C6002 NCS31HJ-470X C CAPACITOR 47pF 50V J
C6003 QETN1HM-105Z E CAPACITOR 1uF 50V M
C6004 QETN1HM-475Z E CAPACITOR 4.7uF 50V M
C6005 QETN1HM-335Z E CAPACITOR 3.3uF 50V M
C6006 QETN1CM-336Z E CAPACITOR 33uF 16V M
C6007 QETN1HM-335Z E CAPACITOR 3.3uF 50V M
C6008 QETN1HM-224Z E CAPACITOR 0.22uF 50V M
C6009 QETN1CM-226Z E CAPACITOR 22uF 16V M
C6010 QFVJ1HJ-104Z MF CAPACITOR 0.1uF 50V J
C6011 QETN1CM-107Z E CAPACITOR 100uF 16V M
C6012 NCS31HJ-101X C CAPACITOR 100pF 50V J
C6013 NCB31HK-333X C CAPACITOR 0.033uF 50V K
C6014 NCB31HK-472X C CAPACITOR 4700pF 50V K
C6015 QFLC1HJ-103Z M CAPACITOR 0.01uF 50V J
C6016 QETN1CM-107Z E CAPACITOR 100uF 16V M
C6017 QETN1HM-225Z E CAPACITOR 2.2uF 50V M
C6018 QETN1HM-226Z E CAPACITOR 22uF 50V M
C6019 NCB31HK-333X C CAPACITOR 0.033uF 50V K
C6020 NCB31HK-332X C CAPACITOR 3300pF 50V K
C6021 QFVJ1HJ-474Z MF CAPACITOR 0.47uF 50V J
C6022 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C6023 QETN1HM-225Z E CAPACITOR 2.2uF 50V M
C6024 QEKC1HM-225Z E CAPACITOR 2.2uF 50V M
Symbol No.
Part No. Part Name Description Local
R3006 NRSA63J-750X MG RESISTOR 75
Ω
1/16W J
R3007 NRSA63J-750X MG RESISTOR 75
Ω
1/16W J
R3008 NRSA63J-750X MG RESISTOR 75
Ω
1/16W J
R3009 NRSA63J-750X MG RESISTOR 75
Ω
1/16W J
R3010 NRSA63J-750X MG RESISTOR 75
Ω
1/16W J
R3011 NRSA63J-750X MG RESISTOR 75
Ω
1/16W J
R3021 NRSA63J-391X MG RESISTOR 390
Ω
1/16W J
R3022 NRSA63J-271X MG RESISTOR 270
Ω
1/16W J
R3023 NRSA63J-181X MG RESISTOR 180
Ω
1/16W J
R3024 NRSA63J-471X MG RESISTOR 470
Ω
1/16W J
R3025 NRSA63J-391X MG RESISTOR 390
Ω
1/16W J
R3026 NRSA63J-271X MG RESISTOR 270
Ω
1/16W J
R3027 NRSA63J-471X MG RESISTOR 470
Ω
1/16W J
R3028 NRSA63J-910X MG RESISTOR 91
Ω
1/16W J
R3029 NRSA63J-471X MG RESISTOR 470
Ω
1/16W J
R3030 NRSA63J-910X MG RESISTOR 91
Ω
1/16W J
R3031 NRSA63J-151X MG RESISTOR 150
Ω
1/16W J
R6000 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R6001 NRSA63J-104X MG RESISTOR 100k
Ω
1/16W J
R6002 NRSA63J-102X MG RESISTOR 1k
Ω
1/16W J
R6003 NRSA63J-564X MG RESISTOR 560k
Ω
1/16W J
R6004 NRSA63J-222X MG RESISTOR 2.2k
Ω
1/16W J
R6005 NRSA63J-102X MG RESISTOR 1k
Ω
1/16W J
R6006 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R6007 NRSA63J-224X MG RESISTOR 220k
Ω
1/16W J
R6008 NRSA63J-102X MG RESISTOR 1k
Ω
1/16W J
R6009 NRSA63J-473X MG RESISTOR 47k
Ω
1/16W J
R6010 NRSA63J-473X MG RESISTOR 47k
Ω
1/16W J
R6011 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R6012 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R6013 NRSA63J-154X MG RESISTOR 150k
Ω
1/16W J
R6014 NRSA63J-154X MG RESISTOR 150k
Ω
1/16W J
R6015 QRE141J-221Y C RESISTOR 220
Ω
1/4W J
R6016 QRE141J-221Y C RESISTOR 220
Ω
1/4W J
R6017 NRSA63J-152X MG RESISTOR 1.5k
Ω
1/16W J
R6018 NRSA63J-203X MG RESISTOR 20k
Ω
1/16W J
R6019 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R6020 NRSA63J-822X MG RESISTOR 8.2k
Ω
1/16W J
R6021 NRSA63J-203X MG RESISTOR 20k
Ω
1/16W J
R6022 NRSA63J-333X MG RESISTOR 33k
Ω
1/16W J
R6023 NRSA63J-333X MG RESISTOR 33k
Ω
1/16W J
R6024 NRSA63J-204X MG RESISTOR 200k
Ω
1/16W J
R6025 NRSA63J-123X MG RESISTOR 12k
Ω
1/16W J
R6026 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R6027 NRSA63J-472X MG RESISTOR 4.7k
Ω
1/16W J
R6028 NRSA63J-153X MG RESISTOR 15k
Ω
1/16W J
R6029 NRSA63J-752X MG RESISTOR 7.5k
Ω
1/16W J
R6030 NRSA63J-223X MG RESISTOR 22k
Ω
1/16W J
R6031 NRSA63J-102X MG RESISTOR 1k
Ω
1/16W J
R6032 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
VR601 QVQ0306-B24 V RESISTOR
B3000 NRSA63J-0R0X MG RESISTOR 0
Ω
1/16W J
B3200 NRSA63J-0R0X MG RESISTOR 0
Ω
1/16W J
B3201 NRSA63J-0R0X MG RESISTOR 0
Ω
1/16W J
CN300 QGF1205F1-24 CONNECTOR FFC/FPC (1-24)
CN301 QGA2501F1-02 CONNECTOR W-B (1-2)
CN302 QGF1205F1-04 CONNECTOR FFC/FPC (1-4)
CN601 QGF1205C1-04 CONNECTOR FFC/FPC (1-4)
J6001 QNS0170-001 HEADPHONE JACK
JA301 QNZ0697-001 RGB CONNECTOR
JA302 QNN0434-001 PIN JACK
K6001 QQR0621-001Z COIL
K6002 QQR0621-001Z COIL
K6003 QQR0621-001Z COIL
PP300 QZW0038-001 WIRE CLAMP
Symbol No.
Part No. Part Name Description Local
IC411 LA4628 IC
Symbol No.
Part No. Part Name Description Local
