JVC UX-P550 Service Manual

3-17
DVD loading switch board
Block No. [0][4]
DVD servo board
Block No. [0][5]
R4203 QRE141J-2R2Y C RESISTOR 2.2 Ω 1/4W J
R4204 QRE141J-2R2Y C RESISTOR 2.2
Ω 1/4W J
R4205 QRE141J-2R2Y C RESISTOR 2.2
Ω 1/4W J
R4206 QRE141J-2R2Y C RESISTOR 2.2
Ω 1/4W J
R4207 QRE141J-682Y C RESISTOR 6.8k
Ω 1/4W J
R4208 QRE141J-682Y C RESISTOR 6.8k
Ω 1/4W J
R4221 QRE141J-222Y C RESISTOR 2.2k
Ω 1/4W J
R4222 QRE141J-222Y C RESISTOR 2.2k
Ω 1/4W J
R4231 QRE141J-433Y C RESISTOR 43k
Ω 1/4W J
R4232 QRE141J-433Y C RESISTOR 43k
Ω 1/4W J
R4233 QRE141J-433Y C RESISTOR 43k
Ω 1/4W J
R4234 QRE141J-433Y C RESISTOR 43k
Ω 1/4W J
R4301 QRE141J-681Y C RESISTOR 680
Ω 1/4W J
R4302 QRE141J-272Y C RESISTOR 2.7k
Ω 1/4W J
R4303 QRE141J-472Y C RESISTOR 4.7k
Ω 1/4W J
R4304 QRE141J-681Y C RESISTOR 680
Ω 1/4W J
R4305 QRE141J-102Y C RESISTOR 1k
Ω 1/4W J
R4306 QRE141J-102Y C RESISTOR 1k
Ω 1/4W J
R4307 QRE141J-102Y C RESISTOR 1k
Ω 1/4W J
R7500 QRE141J-103Y C RESISTOR 10k
Ω 1/4W J
R7501 QRE141J-134Y C RESISTOR 130k
Ω 1/4W J
R7502 QRE141J-241Y C RESISTOR 240
Ω 1/4W J
R7600 QRE141J-221Y C RESISTOR 220
Ω 1/4W J
R7601 QRE141J-161Y C RESISTOR 160
Ω 1/4W J
R7602 QRE141J-102Y C RESISTOR 1k
Ω 1/4W J
R7603 QRE141J-102Y C RESISTOR 1k
Ω 1/4W J
R7604 QRE141J-122Y C RESISTOR 1.2k
Ω 1/4W J
R7605 QRE141J-182Y C RESISTOR 1.8k
Ω 1/4W J
R7606 QRE141J-222Y C RESISTOR 2.2k
Ω 1/4W J
R7607 QRE141J-272Y C RESISTOR 2.7k
Ω 1/4W J
R7609 QRE141J-102Y C RESISTOR 1k
Ω 1/4W J
R7610 QRE141J-102Y C RESISTOR 1k
Ω 1/4W J
R7611 QRE141J-122Y C RESISTOR 1.2k
Ω 1/4W J
R7612 QRE141J-182Y C RESISTOR 1.8k
Ω 1/4W J
R7613 QRE141J-222Y C RESISTOR 2.2k
Ω 1/4W J
R7614 QRE141J-272Y C RESISTOR 2.7k
Ω 1/4W J
L4401 QQL244K-100Z COIL 10uH K
L4402 QQL244K-100Z COIL 10uH K
 T1002 QQT0253-002 POWER TRANSF UB
 T1002 QQT0370-011 POWER TRANSF
UJ,UN
,US,U
W,UX
 CN101 QGA7901C1-02 CONNECTOR W-B (1-2)
 CN102 QGA7901C1-02 CONNECTOR W-B (1-2) UB
 CN102 QGA7901C1-03 CONNECTOR W-B (1-3)
UJ,UN
,US,U
W,UX
CN103 QGA3901C1-07 CONNECTOR W-B (1-7)
CN104 QGB2510J1-10 CONNECTOR B-B (1-10)
 CN105 QGA7901C1-04 CONNECTOR W-B (1-4)
UJ,UN
,US,U
W,UX
CN401 QGB2510K2-11 CONNECTOR B-B (1-11)
CN402 QGF1205C1-22 CONNECTOR FFC/FPC (1-22)
CN403 QGB2510K2-10 CONNECTOR B-B (1-10)
CN404 QGF1016F3-05 CONNECTOR FFC/FPC (1-5)
CN750 QGF1205F1-15 CONNECTOR FFC/FPC (1-15)
CN751 QGF1205F1-10 CONNECTOR FFC/FPC (1-10)
CN760 QGF1205F1-10 CONNECTOR FFC/FPC (1-10)
JS760 QSW1060-001 ROTARY SW
 RY101 QSK0124-001 RELAY
 S1001 QSW0812-001 VOLTAGE SWITCH
UJ,UN
,US,U
W,UX
S7600 QSW0825-001Z TACT SW
S7601 QSW0825-001Z TACT SW
S7602 QSW0825-001Z TACT SW
S7603 QSW0825-001Z TACT SW
S7604 QSW0825-001Z TACT SW
S7605 QSW0825-001Z TACT SW
S7606 QSW0825-001Z TACT SW
S7607 QSW0825-001Z TACT SW
S7608 QSW0825-001Z TACT SW
S7609 QSW0825-001Z TACT SW
S7610 QSW0825-001Z TACT SW
S7611 QSW0825-001Z TACT SW
Z1001 QNG0003-001Z FUSE CLIP
 Symbol No. Part No. Part Name Description Local
Z1002 QNG0003-001Z FUSE CLIP
Z1003 QNG0003-001Z FUSE CLIP
UJ,UN
,US,U
W,UX
Z1004 QNG0003-001Z FUSE CLIP
UJ,UN
,US,U
W,UX
Z1005 QNG0003-001Z FUSE CLIP
Z1006 QNG0003-001Z FUSE CLIP
Z1007 QNG0003-001Z FUSE CLIP
Z1008 QNG0003-001Z FUSE CLIP
Z1009 QNG0003-001Z FUSE CLIP
Z1010 QNG0003-001Z FUSE CLIP
Z1011 QNG0003-001Z FUSE CLIP
Z1012 QNG0003-001Z FUSE CLIP
 Symbol No. Part No. Part Name Description Local
CN1 QGF1016F3-05 CONNECTOR FFC/FPC (1-5)
S1 QSW1007-001 DETECT SWITCH
 Symbol No. Part No. Part Name Description Local
IC201 LA6502-X IC
IC301 MN2DS0003AA-H IC
IC302 LM1117MP-ADJ-X IC
IC453 S-80827CNNB-W IC
IC505 K4S641632F-TC75 IC(DIGITAL)
IC505 or K4S641632H-TC75 IC(DIGITAL)
IC505 or HY57V641620HGT7 IC
IC509 AT49LV1614T90TC IC (FLASH)
IC701 AK4384VT-X IC
Q101 KTA1001/Y/-X TRANSISTOR
Q101 or 2SB1424/R/-W TRANSISTOR
Q102 2SC4617/R/-X TRANSISTOR
Q103 KTA1001/Y/-X TRANSISTOR
Q103 or 2SB1424/R/-W TRANSISTOR
Q104 2SC4617/R/-X TRANSISTOR
Q105 UN2119-X TRANSISTOR
C101 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C102 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C103 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C104 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C105 NEA70JM-476X E CAPACITOR 47uF 6.3V M
C106 NEA70JM-476X E CAPACITOR 47uF 6.3V M
C107 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C108 NEA70JM-476X E CAPACITOR 47uF 6.3V M
C111 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C204 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C205 NCB31HK-271X C CAPACITOR 270pF 50V K
C206 NDC31HJ-151X C CAPACITOR 150pF 50V J
C208 NCB31HK-561X C CAPACITOR 560pF 50V K
C211 NCB31HK-223X C CAPACITOR 0.022uF 50V K
C212 NCB31CK-103X C CAPACITOR 0.01uF 16V K
C217 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C251 NCB31AK-474X C CAPACITOR 0.47uF 10V K
C253 NCB31HK-561X C CAPACITOR 560pF 50V K
C255 NCB31CK-153X C CAPACITOR 0.015uF 16V K
C256 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C257 NCB31HK-822X C CAPACITOR 8200pF 50V K
C258 NCB31CK-153X C CAPACITOR 0.015uF 16V K
C259 NCB31CK-153X C CAPACITOR 0.015uF 16V K
C260 NCB31EK-223X C CAPACITOR 0.022uF 25V K
 Symbol No. Part No. Part Name Description Local
