JVC UX-P550 Service Manual

3-19
Cassette switch board
Block No. [0][6]
Head amplifier board
Block No. [0][7]
R391 NAD0025-103X N THERMISTOR 10k Ω
R392 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R393 NRSA63J-0R0X MG RESISTOR 0
Ω 1/16W J
R394 NRSA63J-0R0X MG RESISTOR 0
Ω 1/16W J
R395 NRSA02J-0R0X MG RESISTOR 0
Ω 1/10W J
R457 NRSA63J-0R0X MG RESISTOR 0
Ω 1/16W J
R458 NRSA63J-102X MG RESISTOR 1k
Ω 1/16W J
R501 NRSA63J-471X MG RESISTOR 470
Ω 1/16W J
R502 NRSA63J-471X MG RESISTOR 470
Ω 1/16W J
R510 NRSA63J-0R0X MG RESISTOR 0
Ω 1/16W J
R551 NRSA63J-102X MG RESISTOR 1k
Ω 1/16W J
R553 NRSA63J-0R0X MG RESISTOR 0
Ω 1/16W J
R554 NRSA63J-0R0X MG RESISTOR 0
Ω 1/16W J
R555 NRSA63J-0R0X MG RESISTOR 0
Ω 1/16W J
R556 NRSA63J-0R0X MG RESISTOR 0
Ω 1/16W J
R557 NRSA63J-0R0X MG RESISTOR 0
Ω 1/16W J
R558 NRSA63J-102X MG RESISTOR 1k
Ω 1/16W J
R701 NRSA63J-1R0X MG RESISTOR 1
Ω 1/16W J
R702 NRSA63J-0R0X MG RESISTOR 0
Ω 1/16W J
R710 NRSA63J-100X MG RESISTOR 10
Ω 1/16W J
R711 NRSA63J-221X MG RESISTOR 220
Ω 1/16W J
R712 NRSA63J-221X MG RESISTOR 220
Ω 1/16W J
R713 NRSA63J-221X MG RESISTOR 220
Ω 1/16W J
R716 NRSA63J-0R0X MG RESISTOR 0
Ω 1/16W J
R718 NRSA63J-473X MG RESISTOR 47k
Ω 1/16W J
R719 NRSA63J-0R0X MG RESISTOR 0
Ω 1/16W J
R723 NRSA63J-101X MG RESISTOR 100
Ω 1/16W J
R724 NRSA63J-101X MG RESISTOR 100
Ω 1/16W J
R725 NRSA63J-101X MG RESISTOR 100
Ω 1/16W J
R727 NRSA63J-101X MG RESISTOR 100
Ω 1/16W J
R728 NRSA63J-0R0X MG RESISTOR 0
Ω 1/16W J
R909 NRSA02J-0R0X MG RESISTOR 0
Ω 1/10W J
R911 NRSA02J-0R0X MG RESISTOR 0
Ω 1/10W J
L501 NQL044K-100X COIL 0.20
Ω 10uH K
CN101 QGF0523F1-24W CONNECTOR FFC/FPC (1-24)
CN201 QGF1016F2-08W CONNECTOR FFC/FPC (1-8)
CN501 QGF1016F2-19W CONNECTOR FFC/FPC (1-19)
CN502 QGF1016F2-08W CONNECTOR FFC/FPC (1-8)
CN503 QGF1016F2-17W CONNECTOR FFC/FPC (1-17)
K101 NRSA02J-0R0X MG RESISTOR 0
Ω 1/10W J
K102 NRSA02J-0R0X MG RESISTOR 0
Ω 1/10W J
K301 NQR0354-001X FERRITE BEADS
K302 NRSA63J-101X MG RESISTOR 100
Ω 1/16W J
K303 NRSA63J-101X MG RESISTOR 100
Ω 1/16W J
K551 NQR0129-002X FERRITE BEADS
K552 NQR0129-002X FERRITE BEADS
K553 NQR0129-002X FERRITE BEADS
K554 NQR0129-002X FERRITE BEADS
K555 NQR0022-005X FERRITE BEADS
K556 NQR0129-002X FERRITE BEADS
K721 NQR0251-004X FERRITE BEADS
K722 NQR0251-004X FERRITE BEADS
K723 NQR0251-004X FERRITE BEADS
X351 NAX0550-001X CRYSTAL 27.000MHz
 Symbol No. Part No. Part Name Description Local
IC1 SG-105F3-BB,C PHOTO SENSER
D1 1SR139-400-T2 SI DIODE
R371 QRE141J-123Y C RESISTOR 12k
Ω 1/4W J
VR37 QVP0077-103Z TRIM RESISTOR 10k
Ω
CN1 QGF1205F1-09 CONNECTOR FFC/FPC (1-9)
FW100 QUM024-07A2Z3 PARA RIBON WIRE
P1 QNZ0104-001 POST PIN
SW1 QSW0832-001 CASS.SWITCH
SW2 QSW0832-001 CASS.SWITCH
 Symbol No. Part No. Part Name Description Local
SW5 QSW0832-001 CASS.SWITCH
SW6 QSW0859-001 DETECT SWITCH
 Symbol No. Part No. Part Name Description Local
IC32 HA12238F IC R/P Equalizer
IC33 CD4094BC IC
Serial to parallel
port extension
Q302 2SC2001/K/-T TRANSISTOR
Q305 2SC2001/K/-T TRANSISTOR
Q342 KRA111M-T DIGI TRANSISTOR
Q343 2SC3576-JVC-T TRANSISTOR
Q344 2SC3576-JVC-T TRANSISTOR
Q345 2SC3576-JVC-T TRANSISTOR
Q346 2SC3576-JVC-T TRANSISTOR
Q347 KRC107M-T DIGI TRANSISTOR
Q371 KTA1271/OY/-T TRANSISTOR
Q372 KRC107M-T DIGI TRANSISTOR
Q375 2SB562/C/-T TRANSISTOR
Q376 KTC3199/GL/-T TRANSISTOR
D340 MTZJ5.1B-T2 Z DIODE
D375 MTZJ5.1B-T2 Z DIODE
C101 QDGB1HK-821Y C CAPACITOR 820pF 50V K
C102 QDYB1CM-103Y C CAPACITOR 0.01uF 16V M
C103 QFLA1HJ-104Z M CAPACITOR 0.1uF 50V J
C104 QCBB1HK-221Y C CAPACITOR 220pF 50V K
C105 QCBB1HK-391Y C CAPACITOR 390pF 50V K
C106 QERF1HM-225Z E CAPACITOR 2.2uF 50V M
C107 QCBB1HK-271Y C CAPACITOR 270pF 50V K
C109 QEKJ1EM-475Z E CAPACITOR 4.7uF 25V M
C110 QDYB1CM-682Y C CAPACITOR 6800pF 16V M
C113 QFLA1HJ-104Z M CAPACITOR 0.1uF 50V J
C120 QCSB1HK-4R7Y C CAPACITOR 4.7pF 50V K
C121 QCBB1HK-331Y C CAPACITOR 330pF 50V K
C201 QDGB1HK-821Y C CAPACITOR 820pF 50V K
C202 QDYB1CM-103Y C CAPACITOR 0.01uF 16V M
C203 QFLA1HJ-104Z M CAPACITOR 0.1uF 50V J
C204 QCBB1HK-221Y C CAPACITOR 220pF 50V K
C205 QCBB1HK-391Y C CAPACITOR 390pF 50V K
C206 QERF1HM-225Z E CAPACITOR 2.2uF 50V M
C207 QCBB1HK-271Y C CAPACITOR 270pF 50V K
C209 QEKJ1EM-475Z E CAPACITOR 4.7uF 25V M
C210 QDYB1CM-682Y C CAPACITOR 6800pF 16V M
C213 QFLA1HJ-104Z M CAPACITOR 0.1uF 50V J
C220 QCSB1HK-4R7Y C CAPACITOR 4.7pF 50V K
C221 QCBB1HK-331Y C CAPACITOR 330pF 50V K
C300 QEKJ1HM-105Z E CAPACITOR 1uF 50V M
C301 QEKJ1AM-107Z E CAPACITOR 100uF 10V M
C304 QEKJ1CM-106Z E CAPACITOR 10uF 16V M
C306 FQETJ1AM-227Z E CAPACITOR
C307 QDGB1HK-102Y C CAPACITOR 1000pF 50V K
C308 QDXB1CM-152Y C CAPACITOR 1500pF 16V M
C310 QCBB1HK-223Y C CAPACITOR 0.022uF 50V K
C313 QEKJ1AM-107Z E CAPACITOR 100uF 10V M
C314 QCFB1HZ-105Y C CAPACITOR 1uF 50V Z
C316 QFG32AJ-223Z PP CAPACITOR 0.022uF 100V J
C319 QFLC1HJ-472Z M CAPACITOR 4700pF 50V J
C331 QEKJ1CM-476Z E CAPACITOR 47uF 16V M
C340 QEKJ1CM-476Z E CAPACITOR 47uF 16V M
C341 QEKJ1HM-105Z E CAPACITOR 1uF 50V M
C342 QEKJ1CM-476Z E CAPACITOR 47uF 16V M
C371 QEKJ1EM-475Z E CAPACITOR 4.7uF 25V M
C374 QEKJ1AM-107Z E CAPACITOR 100uF 10V M
C376 QDYB1CM-103Y C CAPACITOR 0.01uF 16V M
R101 QRE141J-512Y C RESISTOR 5.1k
Ω 1/4W J
R102 QRE141J-512Y C RESISTOR 5.1k
Ω 1/4W J
R104 QRE141J-222Y C RESISTOR 2.2k
Ω 1/4W J
 Symbol No. Part No. Part Name Description Local
