42
English
Main Specifications
The unit’s specifications and exterior are subject to change without
notice due to improvements.
CD Player Section
System Compact disc digital audio system
Pitch control ±12%
Signal-to-noise ratio 94 dB
Dynamic range (1 kHz) 91 dB
Frequency response 20 Hz ~ 20 kHz
Wow and flutter Less than measurable limit
Total harmonic distortion 0.0063%
CDR Section
System Compact disc digital audio recording
system
Sampling frequency 44.1 kHz
Frequency response 20 Hz ~ 20 kHz
Inputs: Analog (LINE IN) Minimum input level: 300 mV (Full
scale –12 dB)/50 kΩ
Digital (optical) Input level: –23 dBm ~ –15 dBm
(With sampling rate 32 KHz/44.1 KHz/
48 KHz)
Microphone Minimum input level: 3 mV (Full scale
–12 dB)/600 Ω ~ 10 kΩ matching
impedance
Signal-to-noise ratio 97 dB (during playback)
Dynamic range (1 kHz) 93 dB (during playback)
Wow and flutter Less than measurable limit
Total harmonic distortion 0.0042% (during playback)
Timer Section
Timer system DAILY TIMER operation (ON/OFF
timer)
ONCE TIMER operation (ON/OFF
timer)
Clock display 12-hour display (for Caranda and
U.S.A.)
24-hour display (for other countries)
Common Specifications
Output connectors:
Analog LINE x 1 set, 2 V/5 kΩ (Full scale)
Headphones x 1, 4 mW/32 Ω, 8 Ω ~ 1
kΩ matching impedance
Digital OPTICAL x 1, –21 dBm ~ –15 dBm
Other connectors COMPU LINK-4/SYNCHRO x 2
Power requirements AC 120V , 60 Hz (for Canada &
USA) AC 230V , 50Hz, (for UK)
AC 110V/127V/230V, 50Hz/60Hz (for
other countries)
Power consumption 29 W in power ON mode; 6 W in
STANDBY mode
Dimensions 435 mm x 127 mm x 325 mm (W x H x
D)
(17-3/16'in x 5'in x 12-13/16'in)
Mass Approx. 6.3 kg (13.9 lbs)
Accessories
Remote control (RM-SXLR5000J, for
Canada & USA), (RM-SXLR5000E,
for other countries)(1)
AA(15F), R6, SUM-3 dry batteries (to
check operation of remote control) (2)
Pin cables (2)
COMPU LINK-4 cable (1)
XL-R5000.book Page 42 Wednesday, March 29, 2000 6:37 PM
