G-L
(68707
“ON)
Connecting
the
System
Control
Cords
and
Connecting
Auxiliary
Equipment
*
Connect
the
components
as
illustrated.
Video
Disc
Player
VCR
,
DCC
or
MD
oo
nae
e
nave
anneeny
Turntable
iI
Saeceeceve
*
:
: > :
+
DCC:
Digital
Compact
Cassette
Deck
*MD
:
Mini-disc
Player
Graphic
Equalizer
Use
MM-cartridge
type
turntable
only.*
If
the
turntable
is
supplied
with
a
ground
wire,
connect
it
to
the
GND
rh
terminal
where
the
AM
loop
antenna
is
connected.
Tuner/Amplifier
Press
the
middle
of
the
connector
unit
until
it
clicks
into
the
male
connector.
any
other
equipment
3
To
disconnect
Pull
the
connector
out.
Never
pull
on
the
cords
themselves.
a
‘assette
Deck
all
When
connecting
the
components
with
the
system
control
cords,
make
sure
to
connect
the
terminals
having
the
same
names
like
“CONNECTOR-A”
or
“CONNECTOR-B”.
When
recording
an
AM
(MW/LW)
broadcasting
program,
beat
sounds
may
be
heard
and
recorded.
Set
the
BEAT
CUT
selector
to
either
1
or
2,
so
that
beat
sounds
will
not
be
heard
nor
recorded.
CAUTION:
First
make
all
connections
before
plugging
the
Unit
into
an
AC
power
outlet.
Page
4
Connecting
the
Front
Speakers
When
you
use
the
panoramic
shifting
speakers
SP-G70BK
For
each
speaker
connect
one
end
of
the
supplied
speaker
signal
cable
to
the
speaker
terminals
on
the
back
of
the
XT-G7ORBK
and
one
end
to
the
speaker.
On
the
back
panel:
1,
Open
each
terminal.
2.
Insert
the
end
of
the
speaker
signal
cable
as
shown
(be
sure
to
remove
the
insulation
at
the
end
of
each
wire
first).
3.
Close
the
terminals
to
clamp
the
speaker
signal
cables
firmly
in
place.
4.
Connect
the
black
(-),
red
(+),
blue
(—),
and
grey
(+)
terminals
of
the
right
side
speaker
to
the
black
(-),
red
(+),
blue
(--),
grey
(+)
terminals
marked
EX,
EJR
on
the
XT-G70RBK.
Connect
the
black
(—),
red
(+),
blue
(-),
and
grey
(+)
terminals
of
the
left
side
speaker
to
the
black
(-),
red
(+)
blue
(-),
grey
(+)
terminals
marked
FX,
EAL
on
the
XT-G70RBK.
5.
Connect
SPEAKERS
CONTROL
RIGHT
and
LEFT
with
the
supplied
speaker
control
cords.
speaker
signal
cable.
Speaker
contro!
Cord
LEFT
When
you
use
your
own
speakers
Conventional
speakers
1.
Connect
the
(+)
and
(—)
terminals
of
the
right
speaker
to
the
grey
(+)
and
blue
(--)
terminals
marked
EJR
on
the
XT-G70RBK.
2.
Connect
the
(+)
and
(—)
terminals
of
the
left
speaker
to
the
grey
(+)
and
blue
(—)
terminals
marked
EYL
on
the
XT-G70RBK.
Note:
You
can
use
only
FY
R
and
L
terminals
to
connect
conventional
speakers.
Page
5
HayOLD-LX
