JVC XT-G70RBK User Manual

(68707 ON) O-L
Connecting the FM and AM (MW/LW) Antennas
FM Antenna Connections
For Germany
Lj Using the Supplied Wire Antenna
The FM wire antenna supplied can be connected to a FM 75-ohm COAXIAL
as a temporary measure.
Using the Coaxial Type Connector (Not Supplied)
A 75-ohm antenna with coaxial type connector (DIN 45332) should be
connected to the FM 75-ohm COAXIAL terminal.
For Other Continental Europe
(Using the Supplied Feeder Antenna
@ Attach the feeder antenna to the supplied antenna adaptor as shown in the
figure.
@ Connect the antenna adaptor to the FM 75-ohm COAXIAL terminal.
= BUsing FM 75-ohm Antenna Cable (Not Supplied)
@ Open the claws at both sides and remove the cover.
. Qu t @ Move the conductor wire from [1 to[Z} using tweezers or similar tool (only
when using coaxial cable).
@® Fix the coaxial cable and its core.
@ Puton the cover.
®
Connect the supplied antenna adaptor to the FM 75-ohm COAXIAL
@ ® terminal.
9 Note:
Make sure the antenna conductor do not touch any other terminals, connecting
ay cords and power cord on the system. This could cause poor reception.
LA a
<Ry>,, For Germany
Extend the supplied wire antenna horizontally.
oil = For other continental Europe
Unhold the loops of the supplied FM feeder antenna
FM Feeder Antenna and extend them as shown.
Fasten them up in the position which gives you the
best FM reception.
If reception is poor, connect the
outside antenna.
Before attaching a 75-ohm coaxial lead (the kind with a round wire
Outside FM Antenna Wire going to an outside antenna), disconnect the supplied antenna.
How to Strip the 75-ohm Coaxial Cable
1. Strip back the outside covering of the 75-ohm coaxial cable to expose the braided metallic mesh,
2. Pull the mesh back over the cable as shown.
3. Swip the insulation about 10 mm back from the central wire.
4. Attach to the supplied antenna adaptor, as stiown in the diagram above.
1 2
| Ae 3 | one
C= CiE—
| AM (MW/LW) Antenna Connections |
AM (MW/LW) Antenna Wire
If reception is poor, connect
an outside antenna.
AM
EXT
Snap the tabs on the loop
ite Tum the loop until you have into the stots of the base
the best reception. toassemble the AM(MW/
LW) loop.
Gio
Ss
Bay AM (MW/LW) Loop Antenna
ANTENNA
Note:
Even
when
connecting
an
outside
AM
(MW/LW)
antenna,
keep the indoor AM (MW/LW) loop connected.
Page 6
Basic Operations
Turning on the Unit
1. Press the POWER ON/STANDBY
button or the POWER button on the
Remote.
The LED on the Unit goes off.
2. Turn down the VOLUME
control completely.
On the Unit From the Remote
a
vou
To turn the Unit in STADBY mode
Press the POWER ON/
STANDBY button or the
POWER button on the Remote
again.
The LED on the Unit tights up. - “
CAUTION: The small amount of
the power (16 watts) is always
constmed even in STANDBY
mode. To switch off the Unit
completely, unplug the AC
power cord from the AC outlet. e
Playing a Tape
1, Press the EJECT button,
=)=
i
Note: To play a tape recorded with
Dolby NR , see page 11.
Fast Winding or Rewinding
1. Press the <#¢ or BP button.
fm
CAUTION: — The use of C-120 (C-120 minutes turn
around) or thinner tape is not recommended,
since characteristic deterioration may occur
and these tape easily jam in the pinch and the
capstan.
Page 7
2. Put a tape in deck A or deck B.
WgYOLD-1L x
7
3. Select a source, start playing and
adjust the VOLUME control.
On the Unit
STS 8
i
From the Remote
fy
Each time you press the SOURCE
button, the source changes as follows:
[pTAPECSTUNER AUSF HON
VIDEO*-VCR/DCC/MD+-CD.
3. Press the » (or <@ ) button.
ey
by
To stop playing
Press the @ button.
Sie
fm
To stop fast winding or rewinding
Press the @ button.
