ELECTRICAL CONNECTION INSTRUCTIONS
04
CAUTION:
PRIOR TO INSTALLATION OR SERVICE, DISCONNECT POWER TO CONTROLLER.
• Ensure proper controller has been selected for the application.
• Use appropriate gauge wire and ensure that all wiring meets local code.
• When making wire connections, do not pull excessively on controller wires,
as they can become disconnected.
• Properly ground controller.
• When reinstalling controller face or lower cover, do not trap wires between
standoffs and screws.
• Remove lower cover on controller face.
• Make wire connections to electrical connection strip as indicated by Electrical Circuit
and Connection Diagram.
• Reinstall lower cover on controller face.
!
