PARTS LIST
1 110 VAC motor, 60 cycle 1111025
220 VAC motor, 60 cycle 1122025
2 Drive gear 1000103
3 Time dial 1000102
4 Time dial retainer and screw 1000104
5 Chassis screws (4) 4331214
6 Black retainer nuts 1009932
7 Day wheel metal spring assembly 1000117
8 Switch assembly (switch, adj. screw, arm, spring, knob and cover) 1000120
9 15 minute white timing pins (18) 1009955
7 minute yellow timing pins (18) 1009956
3 minute orange timing pins (18) 1009957
Mixed assortment of timing pins (6 each) 1009947
15 hour black timing pins (6) 1009959
10 14 day retained pin set for day wheel 1000114
OTHER COMPONENTS
Relay, 110 VAC, 60 Hz coil, double throw, single pole, 2 HP 1320110
Relay, 220 VAC, 60 Hz coil, double throw, single pole, 2 HP 1320220
Transformer, 110 VAC input, 24 VAC, 30 VA output 1211027
Transformer, 220 VAC input, 24 VAC, 30 VA output 1222024
Key Lock 1009915
Pilot Valve for model 2116 (w/o solenoid) 1003042
