Kaadas L8 - Before Installation Steps

Before Installation
Check Door Open Direction Change latch bolt direction
Right-out Right-in
Left-out Left-in
1. Move the latch bolt
switcher to the other
end as the arrow shows.
2. Push the latch
bolt inside the
mortise.
3. Turn around
180 degree.
4. Let the
latch bolt
eject.
Notice:
Make sure the position of 2 directional screws is faced to the indoor direction,
then fasten them properly.
Directional
screws
