SUMMARY OF AVAILABLE PROCESSES, PRESETS, AND
CONFIGURATION SETTINGS
Clean and Sharpen
Cleans and sharpens the
data.
Relabel
Panoramas
Label_from_image_poses
Attempts to convert the
image poses into GPS and
adds that metadata to images
Stitch
Panoramas
10000 pixels
Stitches images to 10000
pixels.
4000 pixels
Stitches images to 4000
pixels.
Subsample
10 percent
Removes 10% of the total
points.
30 million points
Subsamples to 30 million
points.
5cm
Removes points within 5cm of
each other.
Octree 11 Subsamples data to 11
th
octree.
Zip
Processed Map Zip processed point clouds
only.
Raw Data
Zip raw data (bag file) only.
Stencil Pro was specifically designed to provide a complete toolbox for processing of your
scan data, taking you from a collection of points to an accurate and visually stunning 3D
dataset. In a modular fashion, your processing workflow can be customized, saved, and
reviewed through the user interface. Tasks for georeferencing, point cloud filtering,
conversion to an LAS file, and stitching of panoramas produces output applicable to many
field applications and use cases.
Processing Sequence: Though highly customizable, there is a recommended
sequence for processing data on Stencil Pro for optimal results. For example,
GNSS Correct should be performed prior to Align to retrieve the necessary
information required for correcting the trajectory with GNSS data. Pre-Filter
should also be completed prior to Filtering, as it performs calculations on the
data that will be removed in the subsequent Filter step. For this reason,
tasks are described in the following sections in their suggested order of
processing.
