EXTERNAL SCANNER COMPONENTS
SCANNER P OWER/OPERATING BUTTONS
Start Scanning Push the
button to begin scanning. The LED ring around
the button turns from blue to green or teal when Stencil Pro
scanning has started (takes approximately 4-5 seconds).
To stop scanning, push the Scan button. The LED ring around
the button turns from green/teal to yellow while saving, then
returns to a blue ready state. Wait for the blue indicator
before powering off or beginning a new scan.
Note: Supply power to the scanner by connecting it to the controller through
their respective Power Connectors.
SCANNER CONNECTORS AND PORTS
Power is supplied to the scanner from the controller’s Scanner Power
Connector via the Power Connector.
Data is supplied to the scanner from the controller’s Scanner Data
Connector via the Data Connector.
