Technical Manual Installation
1704045088 - 11/2016Kaba wireless gateway 90 40
5.3 Wall mounting
Before mounting the gateway on the wall, ensure that the wireless components can
be reached via radio [}5.1.2.1].
Two slots are provided on the back of the device for fastening (see arrows).
The housing is to be fastened to the wall with the appropriate fastening material
(screws/dowels).
For wall mounting, it should be taken into consideration that the network cable and,
if necessary, the power supply lead have enough space on the top of the device.
