Access Control Catalog - June 2004
Simplex
®
Simplex
®
1000 Series
Heavy-Duty Lock
Mechanical Features
Construction: Heavy-duty cylindrical lock housing with cast front housing; brass unified trim plate; wrought brass knobs
Installation: ASA 161 door preparation with additional through bore holes required: (1) 1" (25mm) diameter for
combination change, (2)
1
⁄4" (6mm) for mounting lock, and (1) 1" (25mm) diameter for optional passage
feature; (1) 1" (25 mm) diameter cross bore for latch.
Door handing: Factory-handed for left hand doors; field reversible
Numeric pushbuttons: Vandal resistant, 5 button, anodized aluminum, mechanical
Weight: 7.25 lbs. (4.5 kg)
Strike: Standard strike plate; ASA strike plate; strike box
Backset: 2
3
⁄4" (70 mm)
Key override: Compatible with major manufacturers of removable cores: ASSA, Best and Compatibles (6 or 7-pin
length), Corbin / Russwin, Medeco / Yale (6-pin length), Sargent, Schlage
Door thickness: 1
3
⁄8" (35 mm) to 2
1
⁄4" (57 mm)
Finishes: Bright Brass 03 (605); Antique Brass 05 (609); Satin Chrome 26D (626); Bright Chrome 026 (625)
models 101 and 102 only
Control: DF59 keys for combination change; DF5 keys for passage feature
Minimum stile 5" (127 mm)
requirement:
Lock Operation
Combination code: One code per lock made of any combination of one to five numbers (pressed individually
or simultaneously)
Code: Thousands of possible combinations
Emergency access: Optional mechanical key override
Certification and Testing
Fire rating: Three-hour UL/ULC Fire rating for “A” label doors
Environmental Highly weather resistant
operating conditions:
Durability:
Conforms to ANSI 156.2, Grade 1
Warranty: 1 year
Accessories for 1000 See page 49
Series locksets:
