Kaba Simplex Mechanical Pushbutton Locks User Manual

Access Control Catalog - June 2004
Simplex
®
13
Simplex
®
1000 Series
Heavy-Duty Lock
Front Exterior Back InteriorSide Exterior
Model
Locking Device
Compatible with removable core
cylinders (not supplied).
A
ASSA
B
Best & Compatibles (6 or 7-pin length)
C
Corbin/Russwin
M
Medeco*/Yale (6-pin length)
*5-pin Medeco cylinder requires a
special knob spacer. Request spacer
when ordering, part number 201569
(supplied free of charge)
R
Sargent
S
Schlage
03
Bright Brass (605)
05
Antique Brass (609)
026
Bright Chrome (625)
Available for models 101
and 102 only.
26D
Satin Chrome (626)
41
1 per box
Locks
shipped
5 per case
1
1
⁄ 2 " (13 mm)
throw latch
floating
face plate
5
3
⁄ 4 " (19 mm)
throw latch
beveled
face plate
Key Override Finishes Packaging
9"
(229 mm)
3
13
⁄16"
(97 mm)
2
3
⁄8"
(60 mm)
3
1
⁄8"
(79 mm)
7
3
⁄8"
(187
mm)
3
1
⁄4"
(83 mm)
101
Combination entry
102
Combination entry
Key override
103
Combination entry
Passage mode
104
Combination entry
Passage mode
Key override
Items supplied with the lock:
- All hardware required for a complete installation
- Full-scale template
- Combination change access key
- Standard & ASA strikes
- Installation instructions
Example
102 1
6
41
Build the model number with the desired options
Model Locking Device Finish Packaging
B
Key Override
1
041
-
--
-
1
2
3
4
5
• Combination Entry
Model 1011
• Combination Entry
• Passage
Model 1031
• Combination Entry
• Key Override
Model 1021
• Combination Entry
• Key Override
• Passage
Model 1041
2D
