Access Control Catalog - June 2004
Simplex
®
37
Simplex
®
6200 Series
Light Commercial/ Residential Locks
Mechanical Features
Construction: All metal; cast front housing; force-proof clutch-protected exterior thumbturn; interior reinforcing plate
with brass trim plate; fixed wrought brass interior knob
Installation: ASA 161 door preparation with additional feature holes; 2
1
⁄8" (54 mm) diameter through bore for
housing; 1" (25 mm) diameter cross bore for latch; 2 x
1
⁄4" holes for mounting bolts. The lock can be
inverted if the existing auxiliary lock obstructs installation
Minimum stile 5" (127 mm)
requirement:
Door handing:
Factory-handed left; field reversible
Numeric pushbuttons: Vandal resistant, 5 button, anodized aluminum, mechanical
Weight: 4.5 lbs. (2 kg)
Strike: TS strike plate; DB (Deadbolt) strike box
Latch:
1
⁄2" (13 mm) throw latch, floating or flat face plate
Backset: 2
3
⁄4" (70 mm) or 2
3
⁄8" (60 mm) backset
Door thickness: 1
3
⁄8" (35 mm) to 2
1
⁄4" (57 mm), wood or metal
Finishes: 60 Gold Tone, 67 Almond, 85 Black or 86 Gray powder paint
Control: Combination change tool
Lock Operation
Combination code: One code per lock made of any combination of one to five numbers (pressed individually
or simultaneously)
Code: Thousands of possible combinations
Certification and Testing
Fire rating: Three-hour UL/ULC Fire rating for “A” label doors
