Kaba Simplex Mechanical Pushbutton Locks User Manual

38
Access Control Catalog - June 2004
Simplex
®
Simplex
®
6200 Series
Light Commercial/ Residential Locks
Model
60
Gold Tone
67
Almond
85
Black
86
Grey
41
1 per box
Locks shipped
5 per case
Finishes Packaging
6204
Combination entry
1
⁄2" (13 mm) throw, floating face plate
Backset 2
3
⁄4" (70 mm) - UL/ULC 3-hour fire rating for
“A” labeled doors
Primary lock
6214
Combination entry
1
⁄2" (13 mm) throw, flat face plate
Backset 2
3
⁄4" (70 mm)
Primary lock
6218
Combination entry
1
⁄2" (13 mm) throw, flat face plate
Backset 2
3
⁄8" (60 mm)
Primary lock
Example
02
6
4
0
4
1
Build the model number with the desired options
Model Finish Packaging
6
2
41
-
--
-
Side Exterior/Interior
Front Exterior
2
9
⁄16"
(65
mm)
2"
(51
mm)
2
13
⁄16"
(72 mm)
8
7
⁄8"
(149
mm)
2
3
⁄4"
(70
mm)
6
Items supplied with the lock:
- Full-scale template - Spanner wrench with combination change tool
- Installation instructions
- Standard strike and strike box
• Combination entry
•
1
⁄2" (13 mm) throw
floating face plate
• Backset 2
3
⁄4" (70 mm)
• Primary Lock
Model 6204
• Combination entry
•
1
⁄2" (13 mm) throw
flat face plate
• Backset 2
3
⁄4" (70 mm)
• Primary Lock
Model 6214
• Combination entry
•
1
⁄2" (13 mm) throw
flat face plate
• Backset 2
3
⁄8" (60 mm)
• Primary Lock
Model 6218

Kaba Simplex Mechanical Pushbutton Locks Specifications

General

Brand	Kaba
Model	Simplex Mechanical Pushbutton Locks
Category	Locks
Language	English
