Access Control Catalog - June 2004
Simplex
®
39
Simplex
®
7100 Series
Light Commercial/ Residential Locks
Construction: All metal; cast front housing; force-proof clutch-protected exterior thumbturn for rim deadlocking models
Installation: 1
3
⁄8" (35 mm) diameter through bore for housing; 1" (25 mm) diameter cross bore for latch (except
7106);
3
⁄4" (19 mm) through bore for combination change sleeve; 2 x
1
⁄4" (63 mm) mounting bolts
Minimum stile 4" (102 mm)
requirement:
Door handing:
Field reversible
Numeric pushbuttons: Vandal resistant, 5 button, anodized aluminum, mechanical
Weight: 2
1
⁄2 lbs. (1.1 kg)
Strike: Models 7102 and 7108: Flat strike plate
Model 7104: Curved lip strike plate
Model 7106: Box strike for inswing doors and flat strike for outswing doors
Latch: 1" (25 mm) tubular deadbolt,
1
⁄2" (13 mm) deadlocking latch,
5
⁄8" (16 mm) rim deadlocking latch
Backset: 2
3
⁄4" (70 mm) or 2
3
⁄8" (60 mm) backset
Door thickness: 1
3
⁄8" (35 mm) to 2
1
⁄4" (57 mm), wood or metal
Finishes: Models 7102, 7104 and 7108: 03 (605) Bright Brass PVD Lifetime Finish; 05 (609) Antique Brass,
26D (626) Satin Chrome; AC (059) Antique Copper; GV (060) Gold Vein; AW (062) Antique White;
SV (061) Silver Vein
Model 7106: 19 (676) Black powder paint; 26D (626) Satin Chrome
Control: Standard Phillips screwdriver to change combination from the inside of the door (not included)
Mechanical Features
Lock Operation
Combination code: One code per lock made of any combination of one to five numbers (pressed individually or simultaneously)
Code: Thousands of possible combinations
