Kaba Solitaire 710-II Series User Manual

I CHECKLIST
710-II/740 SERIES INSTALLATION GUIDE • PK2710/08/02
Page 2
Each Solitaire 710-II or SolitaireSMART 740 lockset includes:
(A) Ouside housing
(B) Mortise (including faceplate B1 and screws B2)
(C) Inside housing
Parts inside hardware bag:
(D) Medallion
(E) One 8-32 x
1
/4" (6.3mm),
5
/64" hex-head setscrew
(F) Two
1
/4" (6.3mm) compression springs
(G) Two square spindles
(K) Two 1" (25mm) Phillips-head combination mounting screws
(L) Sealed battery pack (includes 4 AA batteries)
(M) One 6-32 x
3
/8" (10mm),
5
/64" hex-head screw
(N) Battery cover
(O) One #6 x 1" (25mm) screw for wooden doors
(P) Four 10-24,
1
/8" hex-head mounting screws (length depends on door thickness)
(R) Tube 1
3
/8" (35mm) diameter, for AMM only
(S) Standard strike kit (screws, strike and dustbox)
Mechanical-core override model only (shaded):
(H) Bridge
(I) Two 8-32 x 9/16" (14mm), Phillips-head screws
(J) Cylinder tailpiece
(Q) Cylinder tailpiece retaining clip
Tools in spare parts box (not illustrated):
5
/64" hex (Allen) key
1
/8" hex (Allen) key
Packaged separately with lock shipment:
(T) Override cylinder (mechanical core and removable core override models only)
Shipped separately after lock shipment:
One entry key for mechanical core and removable core override models, per order of identical cylinders
One control key for removable core override models, per order of identical cylinders
Tools Required:
Safety glasses
1
/2" (13mm) chisel
1
/8" (3mm) drill bit
1
/4" (6.5mm) drill bit (SMM only)
7
/16" (11mm) drill bit
7
/8" (22mm) hole saw
1
1
/4" (32mm) hole saw
1
3
/8" (35mm) hole saw
Drill
Awl or center punch
Hammer
Rubber mallet
Flat-head screwdriver
Cleaning supplies (drop cloth, vacuum)
Phillips screwdriver (#2)
Two pliers (for mechanical core and removable core override models)
External ring plier
Fine steel file
Mortising machine
Router
Mortise faceplate router template
Adjustable square
Tape measure
Pencil
Tape
©
2002 Kaba Ilco, Inc. All trademarks and registered trademarks are the property of their respective owners.
