MDM2010 – ILB3210 Installation Guide
1 | Page
1 Preparation
Check the following components before site installation:
1. Modem: MDM2010 with AC power supply adaptor
2. Transceiver (TRX): ILB3210
3. Cable: Single coaxial cable (RG6 75Ohm) (Length 30m)
4. Antenna: Azureshine ANT2010 (75cm)
Modem set
TRX and Coaxial cable
Antenna set
1.1 Modem MDM2010
Manufactured by ST Engineering iDirect (formerly Newtec) and delivered with its AC power
adaptor.
Figure 1. Modem MDM2010
