Kaco Blueplanet 87.0 TL3 Series User Manual

4 Technical data
4.1 Electrical data
KACO blue-
planet
87.0TL3
KACO blue-
planet
92.0TL3
KACO blue-
planet
110TL3
KACO blue-
planet
125TL3
KACO blue-
planet
137TL3
KACO blue-
planet
150TL3
Recommended generator
power range
130.5 kW 138 kW 165 kW 187.5 kW 205.5 kW 225 kW
MPPrange@Pnom
563 V - 1300
V
591 V-1300 V 705 V-1300 V 875 V-1300 V
875 V -1,300
V
960 V-1300 V
Working range
563 V - 1450
V
591 V-1450 V 705 V-1450 V 875 V-1450 V 875 V -1450 V 960 V-1450 V
Rated voltage 600 V 620 V 730 V 900 V 1000 V
Starting voltage 645 V 675 V 805 V 1,000 V 1000 V 1100 V
Open circuit voltage
2
1500 V
Max. input current
3
160 A
Number of strings 1-2
Number of MPP controls 1
Max. short-circuit current (ISC
max.)
300 A
Input source feedback current 0 A
Polarity safeguard no
String fuse no
DC overvoltage protection Yes
KACO blue-
planet
87.0TL3
KACO blue-
planet
92.0TL3
KACO blue-
planet 110TL3
KACO blue-
planet 125TL3
KACO blue-
planet 137TL3
KACO blue-
planet 150TL3
AC Output levels Output levels (AC)
Nominal power 87 kVA 92 kVA 110 kVA 125 kVA 137 kVA 150 kVA
Rated voltage 380 V (3P+PE) 400 V (3P+PE) 480 V (3P+PE) 600 V [3P+PE] 660 V (3P+PE)
Voltage range: continuous
operation
300 V - 437 V 300 V - 460 V 300 V - 552 V 480 V - 690 V 480 V - 760 V
Rated current 3 x 132.3 A 3 x 132.3 A 3 x 132.3 A 3 x 120.3 A 3 x 132.3 A 3 x 131.2 A
Max. continuous current 3 x 132.3 A
Contribution to peak short-
circuit current ip
193 A
Initial short-circuit alternating
current (Ik" first single period
effective value)
137 A
2
A brief open circuit voltage of up to 1600 V
dc
(max. 15 hours a year) is admissible for the device.
Due to the brief open circuit voltage exceedance, there is no guarantee that the integrated overvoltage protection
will work correctly if the ambient temperature is > 40°C.
3
The "Max. input current" is the maximal theoretical value during operation at full power and minimal MPP voltage.
The inverter will clip to the maximum AC power output.
The "Max. short-circuit current (ISCmax.)" defines together with open circuit voltage (Uocmax) the characteristic of
the connected PV generator. This is the relevant value for string sizing and is the absolute maximal limit for inverter
protection. The connected PV-Generator must be designed, that the max short circuit current is below or equal to IS-
Cmax of the inverter under all foreseeable conditions. In no condition the design may result in a greater short circuit
current than ISCmax of the inverter.Configuring the PV generator [See section7.6.2}Page25].
KACO blueplanet 87.0 TL3 KACO blueplanet 92.0 TL3 KACO blueplanet 110 TL3 KACO blueplanet 125 TL3
KACO blueplanet 137 TL3 KACO blueplanet 150 TL3
Page 12
EN-US
