BRIEF DESCRIPTION
LOCATION DRAWING
Arrangement of functional assemblies
Built-in cooker EHC
1. Cooking hob with cooking zones
2. Knobs of the cooking zones control
3. Knobs of the oven temperature control
4. Knobs of the oven operating functions
5. Pilot light ON / OFF (yellow)
6. Oven temperature - pilot light (red)
7. Control panel
8. Oven
9. Electronic programmable control
Built-in oven EHK
Built-in oven EH
Depending on the technical equipment, different
models are provided with different control panels
and relevantly arranged operating elements.
