Kaiser EHC - Equipment; Cooking Zones and Relevant Operating Elements

16
EN
EQUIPMENT
COOKING ZONES AND RELEVANT
OPERATING ELEMENTS
EHC6172*, EHK6162*, EHK6132, EHK6152*
1. Knob of the cooking zone in front (left)
Ø120/ Ø210 mm 0,75 / 2,2 kW
2. Knob of the cooking zone behind (left)
Ø145 mm 1,2 kW
3. Knob of the cooking zone behind (right)
Ø140x250 mm 1,1 / 2,0 kW
4. Knob of the cooking zone in front (right)
Ø180 mm 1,8 kW
EHC 6472*
1. Knob of the cooking zone in front (left)
Ø120/Ø180 mm 0,8 / 1,7 kW
2. Knob of the cooking zone behind (left)
Ø140x250 mm 1,1 / 2,0 kW
3. Knob of the cooking zone behind (right)
Ø180 mm 1,8 kW
4. Knob of the cooking zone in front (right)
Ø145 mm 1,2 kW
* -
Modification
3
1
2
4
2
3
4 1
4
1
2 3
1 2 3 4
