15KaCool D02.02.2017
Technical Data
Operating data
Unit size: model 1 model 2 model 3 model 4 model 5 model 6
AC fans, 2-pipe model
Min./max. cooling output
*1
W 1840 - 2680 2250 - 4330 2940 - 5020 4210 - 6160 5310 - 9510 5310 - 11100
Min./max. heat output
*2
W 1350 - 2040 1570 - 3180 6340 - 11570 9510 - 14620 11300 - 21932 11300 - 26310
Min./max. air volume m³/h 310 - 520 320 - 710 430 - 550 630 - 1140 710 - 1500 710 - 1820
Min./max. sound pressure level
*3
dB(A) 24 - 36 24 - 44 32 - 50 24 - 39 25 - 44 25 - 49
Min./max. sound power level dB(A) 33 - 45 33 - 53 41 - 59 33 - 48 34 - 53 34 - 58
AC fans, 4-pipe model
Min./max. cooling output
*1
W 1850 - 2700 2090 - 3930 2720 - 4530 4140 - 6340 4490 - 8770 4990 - 10200
Min./max. heat output
*2
W 2630 - 3780 1490 - 2950 3310 - 5330 6710 - 10170 7310 - 12400 7310 - 14345
Min./max. air volume m³/h 310 - 520 320 - 710 430 - 880 630 - 1140 710 - 1500 710 - 1820
Min./max. sound pressure level
*3
dB(A) 24 - 36 24 - 44 32 - 50 24 - 39 25 - 44 25 - 49
Min./max. sound power level dB(A) 33 - 45 33 - 53 41 - 59 33 - 48 34 - 53 34 - 58
EC fans, 2-pipe model
Min./max. cooling output
*1
W 1840 - 2750 2240 - 4330 2560 - 5020 4210 - 6330 5290 - 10750 –
Min./max. heat output
*2
W 4150 - 6480 4730 - 9770 5475 - 11570 9510 - 15060 10915 - 23770 –
Min./max. air volume m³/h 310 - 535 310 - 710 360 - 880 630 - 1165 710 - 1770 –
Min./max. sound pressure level
*3
dB(A) 24 - 38 24 - 45 28 - 51 24 - 39 25 - 48 –
Min./max. sound power level dB(A) 33 - 47 33 - 54 37 - 60 33 - 48 34 - 57 –
EC fans, 4-pipe model
Min./max. cooling output
*1
W 1850 - 2770 2090 - 3930 2380 - 4530 4300 - 6510 4980 - 9870 –
Min./max. heat output
*2
W 2760 - 4070 2295 - 3765 2540 - 4220 6970 - 10450 6020 - 10645 –
Min./max. air volume m³/h 310 - 535 310 - 710 360 - 880 630 - 1165 710 - 1770 –
Min./max. sound pressure level
*3
dB(A) 24 - 38 24 - 45 28 - 51 24 - 39 25 - 48 –
Min./max. sound power level dB(A) 33 - 47 33 - 54 37 - 60 33 - 48 34 - 57 –
*1 at CHW 7/12 °C, t
L
= 27°C, 48% relative humidity
*2 at LPHW 75/65, t
L
= 20°C
*3 Sound pressure level data for a room size 100m
3
, reverberation time 0.5 seconds, sound absorption 9 dB(A).
3.5 Operating Data
