M-Bus Mster MultiPort 250D
602602 602 602 602
M-Bus Master
Bus topology with cble looped through meters.
602602 602 602 602
M-Bus Master
Bus topology with ech individul meter connected to the bus.
602
602
602
602
M-Bus Master
Str topology connecting ech individul meter directly to the M-Bus Mster.
