M-Bus Mster MultiPort 250D
3 Connections
All connections in MultiPort 250D re screw terminls
with mx. cble size of 2 mm
2
.
The protection clss of M-Bus Mster MultiPort 250D cn
be up to IP 67. IP 67 mens full dust protection s well
s wter tightness for minimum 30 minutes down to 1
metre.
In order to obtin the highest IP protection, the cbles
used must be correctly mounted through the mster’s
unions.
USB RS-485
RS-232 4 sets of
M-Bus outputs
M-Bus input for
cscde mode
Mins 100-230 V
50/60 Hz
