Kane 3200 - METER RECALIBRATION AND SERVICE; DETAILED TECHNICAL SPECIFICATIONS; Measurement Scales and Resolutions; Accuracy, Range, and Battery

5. METER ANNUAL RECALIBRATION AND SERVICE
The meter should be re-calibrated and serviced annually by a Kane approved service
centre.
Local regulations may require more frequent re-calibration.
Calibration is performed in firmware and there are no user accessible adjustments or
user serviceable parts.
6. SPECIFICATION
Scale Range Highest Resolution
Mbar
+
200 0.01
Pa
+
9999 1
hPa
+
200 0.01
kPa
+
20 0.001
PSI
+
3.0 0.001
mm Hg
+
150 0.01
mm Wg
+
2100 0.01
In Wg
+
80 0.01
NOTE: The nominal range is plus and minus 200 mbar. The meter does not auto-
range and so when Pa units are selected the full operating range cannot be
displayed and the user must select an alternative range for measurements above
999 Pa.
ACCURACY:
+
0.5 mbar or
+
0.5% of reading whichever is greater. Maximum over-
range without damaging the sensor is 1000 mbar.
BATTERY LIFE: Greater than 250 hours continuous operation with a 9 V PP3
alkaline battery.
AMBIENT TEMPERATURE RANGE: 0
o
C to
+
50
o
C
AMBIENT HUMIDITY: 10% RH to 90% RH non-condensing
DIMENSIONS:
Weight: 295 grams with battery
Handset: 160mm x 80mm x 40mm (180mm including spigots)
Ambient Operating Range:
+
0
o
C to
+
45
o
C 10% to 90% RH non-condensing
Power Supply: 9 Volt PP3 alkaline battery
