Kane 456 - Page 13

Page 13
O2/EFF display
NAT
GAS
→
Fuel type
O2
9.8%
→
Oxygen (%) left after combustion. Should be
20.9% ± 0.3% in fresh air.
Efg
81.
1%
→
Gross efficiency
Tf
145.1C
→
Flue temperature (
o
C).
Ta
5.4C
→
Inlet temperature (
o
C). Normally set by flue
probe during fresh air purge.
∆
T
139.7C
→
Differential temperature
Press / to print a full combustion test, (or send to PC via optional
Wireless module).
Hold / for 2+ seconds to log a full combustion report.
AUX display
P
0.00
→
The AUX (auxillary) display can be
customised via MENU / SCREEN / AUX.
R
0.0008
→
The parameters displayed on lines 1, 2, 3, 4,
5 and 6 can be set by the user.
CO
52
p
→
They remain the AUX parameters until
changed by the user.
CO2
6.3
%
→
NO
-
N/F
-
→
NO sensor not fitted
NOx
-
N/F
-
→
NO sensor not fitted
Press / to print a full combustion test, (or send to PC via optional
Wireless module).
Hold / for 2+ seconds to log a full combustion report.
