4.3 PRESSURE/TEMPERATURE TESTING
Select “Prs/Temp”. The pump stops automatically. Press / to auto-
zero the pressure sensor. Using the black connectors and manometer hose, connect
to P1 for single pressure or P1 and P2 for differential pressure.
PRS/TEMP display
PR
S
0.01m
→
Normal response or smoothed (damped)
response can be selected via “Menu”.
m=
mbar
→
‘High’ or ‘Low’ resolution readings can be
selected via “Menu”.
→
Pressure units can be selected via “Menu”.
T1
75.1C
→
Eg Flow Temp
T2
40.2C
→
Eg Return Temp
∆
T
34.9C
→
Differential Temp
Press / to print a full pressure test, (or send to PC via optional Wireless
module).
Hold / for 2+ seconds to log a pressure report.
Viewing / printing a logged pressure/temp test
Select MENU / REPORT / PRS-TEMP / VIEW
Use or to select the log number to be printed.
Press / to print the test, (or send to PC via optional Wireless module).
WARNING
Before using the KANE456 to measure the pressure of a gas/air ratio valve, read the
boiler manufacturer’s instructions thoroughly. If in doubt contact the boiler
manufacturer.
After adjusting a gas/air ratio valve it is essential that the CO, CO
2
and CO/CO
2
ratio
readings are within the boiler manufacturer’s specified limits.
