Page 54
DISPLAYING THE NO READING
Select “Menu” on the rotary switch and navigate using the function buttons:
= Scroll up
= Scroll down
= Enter
Select SCREEN and then select AUX
Choose a line to display the required readings as below
AUX display
P 0.00
→
The AUX (auxillary) display can be
customised via MENU / SCREEN / AUX.
R 0.0008
→
The parameters displayed on lines 1, 2, 3, 4,
5 and 6 can be set by the user.
CO 52p
→
They remain the AUX parameters until
changed by the user.
CO2 6.3%
→
NO 100p
→
NOx 105p
→
NOTE: To EXIT the MENU at any time simply move the rotary switch to any
position other than MENU. Any changes that have not been “entered” will
be ignored.
Use or to navigate to the main menu option SCREEN.
Press .
Use or to navigate to the sub menu option AUX.
Press .
