KanexPro EXT-18GHDMIWL - 4 Specifications

4
4. Specifications
Technical
HDMI Compliance
HDMI 1.3
HDCP Compliance
HDCP 1.4
Video Bandwidth
6.75Gbps
Video Resolution
1080p, 1080i, 720p, 720i, 480p, 480i, the maximum up to
1920×1080@60Hz
The PC resolution is up to 1920×1200@60Hz
Color Space
RGB/YCbCr 4:4:4, YCbCr 4:2:2, YUV 4:2:0
Color Depth
8/10/12-bit
HDMI Audio Formats
PCM 2.0CH 32KHz/44.1KHz/48KHz
ESD Protection
Human body model — ±8kV (Air-gap discharge) &
±4kV (Contact discharge)
Connections
Transmitter
Inputs: 1x HDMI Type A [19-pin female]
1x SERVICE [Micro USB, Update port] Outputs: 1x IR
OUT [3.5mm Stereo Mini-jack]
2x WiFi OUT [WiFi antenna]
Receiver
Inputs: 1x IR IN [3.5mm Stereo Mini-jack] 2x WiFi IN [WiFi
antenna]
1x SERVICE [Micro USB, Update port] Outputs: 1x HDMI
Type A [19-pin female]
Mechanical
Housing
Plastic Enclosure
Color
Black
Dimensions
Transmitter / Receiver:
76mm [W] x 98mm [D] x 21mm [H]
Weight
Transmitter / Receiver: 100g
Power Supply
Input: AC100 - 240V 50/60Hz
Output: DC 5V/1A
Power Consumption
Transmitter: 2.25W, Receiver: 1.8W
Storage Temperature
-4 - 140°F / -20 - 60°C
Relative Humidity
20 - 90% RH (no condensation)
Resolution / Cable
Length
1080P60Hz -
Feet / Meters
HDMI IN / OUT
42ft / 15M
The use of “Premium High-Speed HDMI” cable is highly recommended.
