The following is IR system diagram about IR cable use method.
DVD
DVD remote
7. Application Example
The transmission distance extends up to 100M .
Transmitter Receiver
DVD or Blu-ray Player TV
Receiver
Transmitter
PAIR SERVICE IR OUT
LINK
HDMI
IN
DC 5V
